16 | English
Operation
 Protect the construction site radio against moisture
and direct sunlight.
Audio Operation (see figures B and C)
Switching Audio Operation On/Off
To switch on audio operation (radio and external playback
devices), press the On/Off button 26. The display 27 goes on
and the last set audio source after switching off is activated.
When the construction site radio is in the energy saving mode
(see "Energy Saving Mode", Page 18), press the On/Off but-
ton 26 twice to switch on audio operation.
To switch off audio operation, press the On/Off button 26
again. The current audio source setting is stored.
To save energy, only switch the construction site radio on
when using it.
Adjusting the Volume
To increase the volume, turn the "Volume" 25 adjustment
knob clockwise; to reduce the volume, turn the adjustment
knob anticlockwise. The volume setting (value between 0 and
20) appears for a few seconds in indicator d on the display.
Before adjusting or changing a radio station, set the volume to
a lower setting; before starting an external audio source, set
the volume to medium.
Adjusting the Sound
An equalizer is integrated in the construction site radio for op-
timal sound reproduction.
The treble and bass setting can be manually changed or sound
pre-sets for various music styles can be used. The following
pre-programmed settings are available: "JAZZ", "ROCK",
"POP" and "CLASSICAL" apart from the individually pro-
grammable setting "CUSTOM".
To select one of the stored sound pre-sets, press the "Equal-
izer" button 15 until the desired setting is indicated in indica-
tor a on the display.
Changing the "CUSTOM" Setting:
– Press the "Custom" button 17 once. The "BAS" indicator
c flashes on the display and the stored bass level flashes in
indicator d.
– Set the desired bass level (value between 0 and 10). To in-
crease the bass level, turn the "Bass/Treb" adjustment
knob 25 clockwise; to reduce the bass level, turn the ad-
justment knob anticlockwise.
– To store the set bass level, press the "Custom " button 17
a second time. The "TRE" indicator b flashes in the display
for the following treble adjustment, and the stored treble
value flashes in indicator d.
– Set the desired treble level (value between 0 and 10). To
increase the treble level, turn the "Bass/Treb" adjustment
knob 25 clockwise; to reduce the treble level, turn the ad-
justment knob anticlockwise.
– To store the set treble level, press the "Custom" button 17
a third time.
1 609 92A 2NE | (19.4.16)
Selecting an Audio Source
To select an audio source, press the "Source" button 22 until
indicator m for the desired internal audio source (see "Set-
ting/Storing Radio Stations", page 16) or external audio
source (see "Connecting External Audio Sources", page 17)
appears in the display:
– "FM": FM radio,
– "AM": AM radio,
– "AUX 1": External audio source (e.g. CD player) via the
3.5 mm socket 28 on the side,
– "AUX 2": External audio source (e.g. MP3 player) via the
3.5 mm socket 35 in the digital media bay,
– "USB": External audio source (e.g. USB stick) via the USB
port 33,
– "SD": External audio source (SD/MMC card) via the
SD/MMC slot 34.
Setting the Rod Antenna
The construction site radio is provided with a mounted rod an-
tenna 10. For radio operation, point the rod antenna toward
the direction that enables the best reception.
When the reception is insufficient, position the construction
site radio at a different location that enables better reception.
Note: When operating the construction site radio in the direct
vicinity of radio-communication equipment or radio trans-
ceivers, or other electronic equipment, the radio reception
can be subject to interference.
If the rod antenna 10 should become loose, tighten it directly
at the housing by turning in clockwise direction.
Setting/Storing Radio Stations
Press the "Source" button 22 until "FM" is indicated for the
ultra-short wave reception range or "AM" for the medium
wave reception range in display element m.
To set a certain radio frequency, turn the "Tune" adjust-
ment knob 19 clockwise to increase the frequency, and anti-
clockwise to decrease it. During setting, the frequency is indi-
cated in display section n, then in j.
To scan for radio stations with a high signal strength,
press and briefly hold the "– Seek" button 23 to scan down
and the "Seek +" button 21 to scan up the frequency scale.
The frequency of the found radio station is briefly indicated in
display n and then in j.
When the reception of a suitable signal is sufficiently strong,
the construction site radio automatically switches to stereo
reception. The indicator for stereo reception i appears on the
display.
To store a set station, press the "Memory" button 16. The
"PRESET" indicator e flashes in the display and the number
of the last preset in d. To select a preset, press the "– Seek"
button 23 to scan down and the "Seek +" button 21 to scan
up, until the desired preset is displayed in indicator d. Press
the memory button 16 again to store the set station as the se-
lected preset. The indicators e and d no longer flash.
A total of 20 FM and 10 AM stations can be preset. Please
note that an already occupied preset is overwritten when a
new radio station is assigned to it.
