Mounting The Siren - Federal Signal SST3-MV Mode D'emploi

Qty. Description
1 Adapter
1 Gasket, Adapter
1 Connector Plug, 4-Position
1 Connector Plug, Tone Selector
Operating Voltage:
Operating Current:
Sound Output:
Wail
Yelp
Horn
Weight (approx.):
Dimensions (HWD): 14.5 in x 12 in x 9 in

Mounting the Siren

The Model SST3-MV can be attached to any relatively flat
surface or to a variety of electrical wall boxes. A four-position
plug is supplied for electrical connection. In addition, two #8-
32 x 3-1/4 inch slotted machine-screws are included to attach
the unit to a four-inch square electrical box. After the mounting
method and location have been selected, follow the procedure in
the appropriate section below. For clarity, The speaker portion of
SST3-MV is not shown in the illustrations.
The speaker and its base assembly provides three degrees of
freedom, allowing the siren to be oriented for any coverage pattern
desired. The angle is adjusted with hand-tightened nuts that require
minimal torque to maintain the position of the siren.
Installation and Maintenance Instructions
Table 1 Kit contents
Table 2 Specifications
120/240 Vac, 50/60 Hz, 24 Vdc
Voltage
120 Vac
240 Vac
24 Vdc
dB(A) at 10 ft on Axis
109.5
111
107
4.4 lb (2.173 kg)
(36.83 mm x 30.48 mm x 22.86 mm)
Model SST3-MV Siren
Part Number
K8476121-04
K8476122
K140340
K140389-04
Current
210 mA
120 mA
600 mA
dB(A) UL Rating
100
100
94
7
