MCA1215 – MCA2440
No. in
Explanation/function
fig. 2, page 4
1 On/Off switch
2 Fan
6.3 Battery charging function
The charging characteristics are referred to as modified IU0U characteristics.
U/V
1 2
I/A
I
100 %
1: I phase (bulk)
At the beginning of the charging process, the flat battery is charged with a constant
current (100 % charge current) until the battery voltage reaches the charging volt-
age. The charging current decreases when the battery has reached this charging
level.
EN
All manuals and user guides at all-guides.com
3 4
U0
Technical description
5 6
U
6 %
U
I
t
