BTL7-S5 _ _ (B)-M _ _ _ _ -A/B/CD/Y/Z(8)-NEX-S32/KA _ _
Micropulse Transducer - Rod Style
10
Type code
BTL7 standard
Micropulse transducer
SSI interface
Supply voltage:
5 = 10...30 V DC
Data format:
24 bit
0 = Binary, rising
1 = Gray, rising
2 = Binary, falling
3 = Gray, falling
Resolution:
1 = 1 µm 3 = 10 µm
2 = 5 µm 4 = 20 µm
Synchronous/asynchronous operation:
B = Synchronous operation
Without B = Asynchronous operation
Nominal length (4-digit):
M0500 = Metric specification in mm, nominal length 500 mm
(M0025...M1016: A8, B8, Y8, Z8)
(M0025...M2000: CD)
(M0025...M5500: A, B, Y, Z)
Rod version, fastening:
A = Metric mounting thread M18x1.5, for flat seal, rod diameter 10.2 mm
B = Metric mounting thread M18x1.5, O-ring, rod diameter 10.2 mm
Y = 3/4"-16UNF thread, for flat seal, rod diameter 10.2 mm
Z = 3/4"-16UNF thread, O-ring, rod diameter 10.2 mm
A8 = Metric mounting thread M18x1.5, for flat seal, rod diameter 8 mm
B8 = Metric mounting thread M18x1.5, O-ring, rod diameter 8 mm
Y8 = 3/4"-16UNF thread, for flat seal, rod diameter 8 mm
Z8 = 3/4"-16UNF thread, O-ring, rod diameter 8 mm
CD = Metric mounting thread M22×1.5, O-ring, rod diameter 12.7 mm
Electrical connection:
S32 = 8-pin, M16 plug per IEC 130-9
KA_ _ = Cable, axial (e.g. KA05 = 5 m)
24 english
BTL7 - S 5 0 1 B - M0500 - B - NEX - S32
25 bit
6 = Binary, rising A = Binary, rising
7 = Gray, rising B = Gray, rising
8 = Binary, falling C = Binary, falling
9 = Gray, falling D = Gray, falling
5 = 40 µm 7 = 2 µm
6 = 100 µm 8 = 50 µm
26 bit
Ignition protection
"ec" and "tb"
