D - Throttle Decal (Part No. 800-99628)
Max. RPM Idle
Position Position
E - Branding Decal
Branding Decal to identify the Model of RTX Rammer.
F - Noise Decal
Guaranteed Sound Power Level of the machine in dB(A).
G - Spring Safety Decal (Part No. 800-99619)
DO NOT loosen or remove any of the Screws from the underside of the Rammer Leg. The Rammer Leg contains a highly compressed
Spring which may cause serious injury if released by loosening or removing any of the Screws. Contact dealer for more information.
H - Engine Start Decal (Part No. 800-99625)
To Start the Engine, push the Carburettor Primer Bulb 4 times and then pull the Recoil Handle until the Engine fi res.
J - Fuel Valve Decal (800-99634-0)
Fuel Valve 'ON' and 'OFF' positions.
- To START the machine, the Fuel Valve must be in the 'ON' position.
- When the machine is not in use or being transported, the Fuel Valve must be in the 'OFF' position.
K - Serial Plate (Part No. 800-99844)
The Serial Plate contains the machine Serial Number and all other information that you may require when contacting Altrad Belle
regarding your machine.
1. Serial Number.
2. RTX Rammer Model.
3. Year of Manufacture.
4. Machine Weight.
5. Machine Power.
Decals
STOP
Emergency
Engine Stop
Stop
Button
Position
(Petrol Only)
2
1
9
GB
3
5
4
