CAUTION
WARNING
Honda GX100 & GX120
1. Open the fuel cock/tap.
2. Set the speed control lever to the STARTING position (Halfway between HIGH and LOW position).
3. Move the choke lever to the CLOSED position.
4. Push the Carburettor Primer Bulb 4 times (or at least 10 times when the machine is new or after machine has had the fuel drain).
5. Taking a fi rm hold of the Operating handle with one hand, grasp the recoil starter handle with the other, Pull the recoil starter
handle until engine resistance is felt, then allow the starter to return.
6. Taking care not to pull the starter rope fully out, pull the starter handle briskly.
7. Repeat until the engine fi res.
8. Once the engine fi res gradually set the choke lever to the OPEN position.
9. Allow the engine run at idle for a few minutes to warm up.
10. After the engine has warmed up, the machine is ready for operation.
11. Move the throttle lever to the high speed position quickly to prevent damage from occuring to the clutch. The 'Full Throttle' position
of this machine has been preset at the factory to achieve optimum machine performance.
12. With the engine running in the full throttle position, the machine will move forward and compact loose 'lifts'
13. In preparation for stopping the engine, move the throttle lever to the LOW position.
14. Allow the engine to idle for 1-3 minutes.
15. Push and hold the RED Engine Stop button.
16. Close the fuel cock/tap.
17. Pull the recoil starter slowly until you feel resistance. Then release your hand from the starter knob to set it back to its
original position. This will prevent any air or humidity from entering into the cylinder.
Yanmar L48
1. Slide the Engine Speed Control Lever to the RUN position.
2. Taking a fi rm hold of the Operating handle with one hand, grasp the recoil starter handle with the other, Pull the recoil starter
handle until engine resistance is felt, then allow the starter to return.
3. Push the decompression lever down and release it. The decompression lever will automatically return to the original position when
the engine starts.
4. Taking care not to pull the starter rope fully out, pull the starter handle briskly.
5. Repeat until the engine fi res.
CAUTION
6. Allow the engine run at idle for a few minutes to warm up.
7. After the engine has warmed up, the machine is ready for operation.
8. Move the throttle lever to the high speed position quickly to prevent damage from occuring to the clutch. The 'Full Throttle' position
of this machine has been preset at the factory to achieve optimum machine performance.
9.
With the engine running in the full throttle position, the machine will move forward and compact loose 'lifts'
10. In preparation for stopping the engine, move the throttle lever to the LOW position.
11. Allow the engine to idle for 1-3 minutes.
12. To stop the engine, set the engine speed lever to the slide the Engine Speed Control Lever to the STOP position
Start & Stop Procedure
Improper operation can be hazardous. Read and understand this section before you start the machine.
To stop the machine in an emergency, move the Throttle Lever to the Emergency Stop position. This will
immediately stop the machine from vibrating.
In cold weather if you have trouble starting the engine, remove the Oil Plug and add 2cc of engine oil to
the oil port and reinsert the oil plug.
14
