N DESCRIPTION
O.
165 Up-down adjustment screw (A)
166 Prick gear
167 Flat key 4 x 8
168 Ring for shaft 10
169 Down damper for body
170 Up-down adjustment seat
171 Washer 5
172 Spring washer 5
173 Hex bolt M6 x 12
174 Up-down adjustment screw (B)
175 - - -
176 Up-down column
177 Dust adapter
178 Bolt M4 x 16
179 - - -
180 Bolt M5 x 8
181 Cover board
182 Brush cover
183 Brush
184 Brush holding
185 Body
186 Damping ring
187 Bearing 6001-2Z
188
Stator
189 Self-lubricating bearing
190 Ring for shaft 16
191 Gear
PARTS LIST
Please refer to the schematic drawing on page 29.
N
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
DESCRIPTION
O.
Half-round key 5 x 6.5 x 16
Output shaft
Connection shaft (A)
Ring for shaft or hole 35
Bearing 6003-2Z
Gear cover
Bolt M5 x 16
Bolt M5 x 35
Front cover
Inside track
Bearing 6201-2Z
Rotor
Bolt ST4.8 x 70
Press board cover
Blade wrench
Flat washer 3
Hook for blade guard
Hook for limited piece
Screw M6 x 30
Rubber pad
Knob
Main label
Bolt M4 x 12
Small baffle
Big washer 5
Bolt M5 x 10
Body baffle
