English
Installing the Battery Strap Carabiner to
the Lanyard Attachment Point

WARNING: DO NOT attach the lanyard to the battery
strap. Lanyards should only be attached to the lanyard
attachment point.
The carabiner at the end of the battery strap
opened and then attached to the lanyard attachment point.
To open the carabiner:
1. Install battery into tool.
2. Flip open the carabiner tab
3. Pull the tab upward.
4. Move the carabiner locking arm
5. Attach the carabiner locking arm to the lanyard
11
attachment point .
6. Move the locking arm back into place, push the tab back
down so the pin engages the locking arm.
7. The tool is now ready for a lanyard. Refer to Figure D.
Quick-Release Chuck (Fig. A, J)

WARNING: Use only impact accessories. Non‑impact
accessories may break and cause a hazardous
condition. Inspect accessory prior to use to ensure that
it con tains no cracks.
nOTE: The chuck 6
accepts 1/4" (6.35 mm) hex accessories
and 1" (25.4 mm) bit tips only.
Place the forward/reverse button
(center) position and remove battery pack before
changing accessories.
To install an accessory, fully insert the accessory. The
accessory is locked into place (Fig. J).
To remove an accessory, pull the chuck collar
from the front of the tool. Remove the accessory (Fig. J).
OPERATION

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can cause injury.
Installing and Removing the Battery Pack
(Fig. H)
nOTE: For best results, make sure your battery pack is
fully charged.
1
To install the battery pack
battery pack with the rails inside the tool's handle and slide
it into the handle until the battery pack is firmly seated in
the tool and ensure that it does not disengage.
To remove the battery pack from the tool, press the release
2
button and firmly pull the battery pack out of the tool
handle. Insert it into the charger as described in the charger
section of this manual.
Proper Hand Position (Fig. I)

WARNING: To reduce the risk of serious personal
injury, ALWAYS use proper hand position as shown.
10
12
, should be
13
.
14
out to open.
4
in the lock-off
5
away
into the tool handle, align the

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
sudden reaction.
Proper hand position requires one hand on the main
15
handle .
Variable Speed Trigger and Forward/
Reverse Control Button (Fig. A)
The tool is turned on and off by pulling and releasing
3
the variable speed trigger . The farther the trigger is
depressed, the higher the speed of the tool. Your tool is
equipped with a brake. The chuck will stop as soon as the
trigger switch is fully released.
A forward/reverse control button
rotational direction of the tool and also serves as a
lock-off button.
• To select forward rotation (clockwise), release the trigger
and depress the forward/reverse control button on the
right side of the tool.
• To select reverse (counterclockwise), depress the
forward/reverse control button on the left side of
the tool.
nOTE: The center position of the control button locks the
tool in the off position. When changing the position of the
control button, be sure the trigger is released.
nOTE: Continuous use in variable speed range is not
recommended. It may damage the switch and should
be avoided.
nOTE: The first time the tool is run after changing the
direction of rotation, you may hear a click on start up. This is
normal and does not indicate a problem.
Worklights (Fig. A)

CAUTION: Do not stare into worklight. Serious eye
injury could result.
8
There are three worklights
5
collar . The worklights are activated when the trigger
switch is depressed. When the trigger is released, the
worklight will stay illuminated for up to 20 seconds. If
the trigger switch remains depressed, the worklights will
remain on.
nOTE: The worklights are for lighting the immediate work
surface and are not intended to be used as a flashlight.
Mode Selector (Fig. A)
Your tool is equipped with a mode selector
you to select one of three modes. Select the mode based on
the application and control the speed of the tool using the
variable speed trigger switch
Precision Drive (Fig. A)
In addition to normal impacting modes, this tool features
the Precision Drive mode which enables greater control
in lighter applications to avoid damage to materials or
fasteners. It is ideal for light applications such as cabinet
hinge screws or machine screws. Precision Drive mode will
work as a screwdriver in light applications, before hesitating
as the screw head reaches the work piece, and then (if
4
determines the
located around the chuck
7
which allows
3
.
