GB

MAINTENANCE

with leaning brush. (Fig. 12)
CAUTION! Never clean seals, diaphragm
and nozzle or air holes of the spray gun
with metal objects. The ventilation hose
and diaphragm are only solvent-resistant
to a limited extent. Do not immerse in
solvent, only wipe.
10. Remove the adjusting ring (fig. 13,1) arefully from
the union nut (2). Uns rew union nut (2), remove
air ap (3), nozzle (4) and nozzle seal (5).
Thoroughly lean all parts.
Take spe ial are when leaning the intersti es on
the needle (Fig. 14)
11. Clean the outside of the ontainer with a loth soaked in
solvent or water.
12. Assemble the parts again (see "Assembly").
12.1

ASSEMBLY

ATTENTION! Follow the steps described
below exactly for assembly. Otherwise
the spray attachment may be damaged.
ATTENTION! Never operate the device if
the nozzle seal is missing, damaged or
incorrectly mounted. If the nozzle seal is
either missing, damaged or incorrectly
mounted liquids can enter the device and
increase the risk of an electric shock.
1. Push nozzle seal onto the needle so that the groove (slot)
points away from the spray atta hment. (Fig. 15)
2. Pla e nozzle on the needle with re ess downwards.
Attention: Position of needle must be congruent with
the nozzle aperture. (Fig. 16)
3. Pla e air ap on nozzle (pay attention to re esses in the air
ap). (Fig. 17)
4. S rew on union nut. (Fig. 18)
5. Snap the adjusting ring into the union nut. (Fig. 19)
Make sure that the two re esses on the adjusting ring
are engaged in the air ap lamps and that the lever for
adjusting the spray jet width is lo ated on the pin.
6. Pla e the ontainer seal from below on the feed tube and
slide it over the ollar, while turning the ontainer seal
slightly.
7. S rew the feed tube with the ontainer seal into the body
of the gun.
In order to mount the gun more easily apply
lubri ating grease (en losed) liberally to the O-ring
at the spray atta hment (Fig. 20).
22
13
MAINTENANCE
13.1

AIR FILTER

Attention! Never operate the device with
the air filter soiled or missing, as dirt could
be sucked up and affect the operation of
the device.
Always check the air filter before starting
work.
1. Unplug the power plug.
2. Release the air filter ompartment
3. Clean (blow out) or repla e the air filter (Fig. 22,1) depending
on the degree of soiling.
4. Push the lean air filter underneath the fixtures (fig. 22, 2)
on the left and right-hand sides (pay attention to the shape
of the air filter and ompartment).
5. Reatta h the over of the air filter ompartment and lo k
.
13.2

AIR RELIEF VALVE

If paint has entered the ventilation hose, pro eed
as follows:
1. Pull the ventilating hose (Fig. 23, 1) at the top from the
gun body. S rew off the valve over (2). Remove the
diaphragm (3). Clean all the parts arefully.
CAUTION! The ventilation hose and
diaphragm are only solvent-resistant to a
limited extent. Do not immerse in solvent,
only wipe.
2. Pla e the diaphragm in the valve over with the pin fa ing
forward (Also see the marking on the gun body).
3. Turn the body of the gun upside down and s rew on the
valve over from underneath.
4. Pla e the ventilating hose on the valve over and on the
nipple at the gun body.
FinishControl 3500
(fig. 21) and remove.
