TROUBLESHOOTING
System Messages Continued
System Message
Sensor / system time mismatch.
Update time or reconnect a new sensor.
System Fault Detected.
Trend data limit has been reached.
Oldest data will be overwritten.
Very Low Battery
Connect monitor to power supply.
Zeroing Error
System Problems
Problem
Battery not charging or not holding charge. Defective battery.
Monitor freezes and does not turn off.
Wrong date and time.
ICP reading goes negative
Cause
Sensor appears to be zeroed
in the future.
Internal software or hardware
error.
14 days of trend data have
already been collected and the
device has run out of memory.
Not enough battery charge
to power up the system.
System was unable to zero
the sensor.
Cause
Overall system
software or hardware
error.
Internal back up
battery defective.
System not grounded
properly.
Electrical noise from
adjacent devices.
27
Recommendation
• Confirm the monitor has the correct date.
• Use a different sensor.
• Log error code for future reference.
• Reboot monitor. If problem persists turn off the monitor
and contact Technical Support.
• Download trend data to a USB memory device for future
use. Refer to Data Download section.
• Charge the battery by connecting the monitor to the power
supply.
• The monitor can be used while connected to the power
supply.
• Make sure the sensor is connected properly into the
extension cable.
• Make sure the extension cable is connected correctly to
the monitor.
• Make sure to use a CereLink ICP Sensor (refer to
Recommended Accessories).
• Make sure the sensor is zeroed in a shallow pool of sterile
water.
• If problem persists, replace extension cable.
• If problem persists, replace ICP Sensor.
• If problem persists, contact Technical Support.
Recommendation
• Replace battery.
• Refer to Replacing the Battery section.
• Press and hold the power button for several seconds to
force shutdown of the ICP Monitor.
• If problem persists, contact Technical Support.
• Internal battery needs replacement.
• Contact Technical Support.
• Make sure the sensor is connected correctly into the
extension cable.
• Make sure the extension cable is connected correctly to
the monitor.
• Make sure to use a CereLink ICP Sensor (refer to
Recommended Accessories).
• Make sure to use a CereLink Power Supply (refer to
Recommended Accessories).
• Confirm power supply plug is unmodified and properly
connected to a hospital grade system.
• Confirm power supply replaceable plug is attached
properly to the power supply.
• Move the CereLink ICP Monitor away from other devices
that may cause electrical interference.
