EN - ENGLISH
TROUBLESHOOTING
System Messages
System Message
New Sensor Detected!
Previous sensor data will be deleted.
Disconnect new sensor now to stop deletion.
No USB device recognized.
Patient Monitor disconnected.
Screen shot memory full.
The oldest image will be replaced.
Sensor disconnected from the cable.
Sensor or extension cable failure!
Disconnect and replace cable or sensor.
Sensor implanted or not still.
Cause
Stored data will be deleted
when a new sensor is
detected.
Problem with the
connection or the
compatibility of the USB
memory device.
Connection with the
Patient Monitor lost during
the Patient Monitor Setup.
Maximum number of screen
shots has been reached.
ICP sensor disconnected
from the extension cable.
Extension remains
attached to the monitor.
System has detected an
issue with the sensor or
extension cable.
System not grounded
properly.
Electrical noise from
adjacent devices.
System has detected
pulsatility in the pressure
sensor reading. This
indicates the sensor is
implanted or moving prior
to the zeroing process.
26
Recommendation
• Download data prior to connecting a new sensor.
Refer to Data Download section.
• Reconnect the USB memory device and try the
operation again.
• Make sure the USB memory device is plugged in all
the way.
• Make sure the USB memory device meets the
minimum specifications. Refer to Data Download
section.
• Use a different USB device with no files stored in
memory.
• Reboot monitor and try again.
• Reconnect Patient Monitor and perform the
calibration process.
• Make sure interface cable is connected properly.
• Replace the interface cable.
• Make sure Patient Monitor is turned on.
• Download all screenshot to a USB memory device.
Refer to Data Download section.
• Disconnecting the cable from the monitor will not
trigger this message.
• If message appears while sensor is still attached,
sensor or the cable may be damaged.
• Make sure the sensor is connected correctly into
the extension cable.
• Make sure the extension cable is connected
correctly to the monitor.
• Make sure to use a CereLink ICP Sensor (refer to
Recommended Accessories).
• Make sure to use a CereLink Power Supply (refer to
Recommended Accessories).
• Confirm power supply plug is unmodified and
properly connected to a hospital grade system.
• Confirm power supply replaceable plug is attached
properly to the power supply.
• Move the CereLink ICP Monitor away from other
devices that may cause electrical interference.
• If problem persists, replace extension cable.
• If problem persists, replace ICP Sensor.
• If problem persists, replace power supply.
• If problem persists, contact Technical Support.
• An implanted sensor will not be zeroed.
• Place sensor in a shallow pool of sterile water and
make sure it is not moving.
• If problem persists, replace extension cable.
• If problem persists, replace ICP Sensor.
• If problem persists, contact Technical Support.
