6. Product Information
6.2.2 Guidance concept
Rotationally secured guidance of a guidance slide on two parallel guidance pipes.
Guidance pipe: Precision pipe to DIN EN 10305, stainless steel section, material 17458,
peak-to-valley height R
Spindle bearing: sealed deep groove ball bearings, slide bearings to order
After receiving this linear unit, check the device for possible damage and missing components.
If you find any faults, inform RK Rose+Krieger GmbH of these immediately. The linear unit is deli-
vered ready for operation, but without a control system and without accessories.

6.3 Dimensions

Linear units are produced individually to length in accordance with your specification.
The width and height of this linear unit is determined from the choice of size and design and can
be taken from the Linear Components catalogue.

6.4 Loading data

In dynamic operation, this must be considered for the design:

6.4.1 Loading data* EP-II

Fx
Length over-
all 500
(mm)
Version
EP-II 40 1000 N
* relating to the guidance slides (bending of guidance body f = 0.5 mm static, end elements sup-
ported)
34
= 0.4 µm
a
Fx max = m*a [m/s
Permitted forces
Fy
500 1000 1500
3500 N 2600 N 1300 N
2
].
Fz
500 1000 1500
2000 N 580 N 120 N
Permitted torques
Mx My Mz
120 Nm 130 Nm 150 Nm
