Gentile Signora, Egregio Signore
ci congratuliamo con Lei per la Sua nuova Cimbali.
Con questo acquisto Lei ha scelto una macchina per caffè
espresso d'avanguardia costruita secondo i più avanzati principi
della tecnica moderna; una macchina che non soltanto è in
grado di offrirLe una perfetta sintesi di efficienza e funzionalità
ma mette a Sua disposizione tutti gli strumenti per darLe la
"sicurezza di lavorare meglio".
Il consiglio di dedicare un poco di tempo alla lettura di questo
Libretto di Uso e Manutenzione nasce dal desiderio di aiutarLa
a prendere confidenza con la Sua nuova macchina; desiderio
che siamo certi Lei condividerà pienamente.
Le auguriamo buon lavoro.
F
Cher Client,
Nous vous félicitons pour l’acquisition de votre nouvelle Cimbali.
Avec cet achat vous avez choisi une machine à café moderne,
construite selon les principes les plus avancés de la technique
d’aujourd’hui, une machine qui vous offre une parfaite synthèse
d’efficacité et de fonctionnalite et qui met ê votre disposition tout
ce dont vous avez besoin pour obtenir un bon travail.
Le conseil que nous vous donnons de consacrer un peu de
votre temps à la lecture de cette brochure vient du désir que
nous avons de vous aider à atteindre une bonne connaissance
de votre nouvelle machine.
Nous sommes certains que vous serez du même avis. Avec nos
meilleurs souhaits de bon travail.
E
Estimado Cliente,
nos felicitamos con Usted para su nueva Cimbali.
Con esta compra Usted ha escogido una máquina para café a
la vanguardia, construida según los principios mas adelantados
de la técnica moderna; una máquina que no sólo le ofrece una
perfecta eficiencia y funcionalidad, mas también le da todo lo
que Usted necesita para alcanzar la garantía de un buen trabajo.
Le aconsejamos de poner un poco de su atención en la lectura
de este manual, consejo que nos viene del deseo de aiudarle a
lograr un buen conocimiento de su nueva máquina.
Estamos seguros que Usted tiene la misma opinión.
Con un deseo particular de buen trabaio
GB
Dear Customer,
We congratulate with you for your new Cimbali.
With this purchase you’ve chosen an up to date machine, built
after the most advanced principles of modern technology, a
unit, which gives you not only a perfect synthesis of efficiency
and functonality, but puts also at your disposal everything you
need for a good working.
The advice we give you of spending a bit of your time in reading
this manual comes from our desire of helping you in reaching
a good knowledge of your new machine.
We’re sure of finding you of the same advice.
With our best wishes of a good work.
La Cimbali
D
Sehr geehrter Kunde,
Wir gratulieren lhnen zur lhrer neuen Cimbali und heissen sie
in unserem Kundenkreis willkommen. Mit diesem Gerät haben
Sie eine Maschine ausgewählt, die nach den letzten technischen
Entwicklungen auf diesem Sektor gebaut wurde: eine Maschine
die mehr als die perfekte Synthese zwischen Leistungsfähigkeit
und Funktionalität anbietet: nämlich die Gewissheit, ein
betriebsicheres, seinen Aufgaben gewachsenes Gerät zu
besitzen.
Wir empfehlen lhnen dieses Handbuch zum Studium, wissend,
dass Sie damit lhre Kenntnisse über lhre neue Maschine
vertiefen können.
Wir verbleiben mit unseren besten Wünschen für ein gutes
Arbeiten mit lhrem neuen Gerät.
La Cimbali
P
Exmª. Senhora, Exm°. Senhor,
Felicitamo-nos e a si pela sua nova Cimbali.
Com deste acquisição escolheu uma máquina para café de
vanguarda, construída segundo os mais avançados principios
da técnica moderna, uma máquina que está não somente em
condições de lhe oferecer uma sintese perfeita de eficiência e
funcionalidade, mas põe à sua disposição todos os instrumentos
para dar-lhe a "segurança de trabalhar melhor".
O conselho de dedicar um pouco de tempo à leitura deste livreto
de uso e manutenção nasce do desejo de o ajudar a tomar
familiaridade com a sua nova máquina; desejo que estamos
certos partilhará plenamente.
Desejamos-lhe bom trabalho.
La Cimbali
La Cimbali
La Cimbali
La Cimbali
Code 442 - 258 - 010 (rev. 04/04)
