Introduction; Installation - Velp Scientifica MST DIGITAL Manuel D'instructions

1. Introduction

The MST magnetic stirrer is a small, simple and effective stirrer.
Thanks to the new brushless motor, the stirrer stays cold even after several days of continuous operation.
Thanks to the white cover surface it is specially designed for microtitrations, and it is extremely useful where reliable and
small instrument is needed.
The stirring speed can be set using the frontal knob within a range of 80 - 1500 rpm
The stirrer display shows the speed set point.
The instrument is equipped with advanced functions as auto-reverse of the stirring direction, intermittent mode programs
and integrated timer to meet users' workflow and safety lock feature to avoid possible alteration of the working conditions.
NOTE: it's important to choose the most suitable magnetic stirring bar related to the quantity and the liquid to be stirred as
well as to the type of the beaker. The magnetic stirring bar that satisfies most of the application is A00001056 (6x35mm).

2. Installation

•
Unpacking
➢ Check the integrity of the unit after unpacking
•
The box includes
➢ MST Digital magnetic stirrer
➢ Instruction manual
➢ Plug for power supply
➢ Switching power supply 100-240 V / 12 V
•
Installation
➢ Place the unit on a non-flammable surface
➢ Make sure that the technical specification of the unit and the power supply line are the same
➢ Place the flasks containing the sample and a suitable magnetic stirring bar on the stirring plate
➢ Connect the instrument to an easily accessible socket (compliant with the current safety norms), using only the
provided power supply and dedicated plug
6
EN
