Radio transmission: the transmitter LED lights up only if the radio transmission was successful. Adding an
intermediate receiver will solve the problem of insuffi cient range. Refer to the Yokis transmitter
instruction booklet for more information.
Frequency band:
WiFi: ........................................................................................................................................ 2400 ÷ 2483,5 MHz
Yokis: ......................................................................................................................................... 2400 ÷ 2480 MHz
Mifare: ................................................................................................................................................... 13,56 MHz
Output power (Max):
WiFi: ........................................................................................................................................................... 20 dBm
Yokis: ......................................................................................................................................................... 10 dBm
Mifare: .....................................................................................................................................-13 dBμA/m @ 10m
Relay output 1 (OP5 / OP5A) ...................................................................................................... 100 mA @ 24 V
Relay output 2 (OP20 - RELAY SPARE) ....................................................................................... 25 mA @ 24 V
Working temperature range: ............................................................................................................... -5 to +45° C
Max. humidity: ........................................................................................................................................... 95% RH
Dimensions (WxHxD): ................................................................................................................202 x 142 x 22 mm
Panel
Power voltage: .................................................................................................................................... 36 to 48 V
Consumption: maximum .......................................................................................................... 130 mA @ 48 V
standby ................................................................................................................ 20 mA @ 48 V
Maximum working power: ..................................................................................................................... max. 6.5 W
Dimensions (WxHxD): ................................................................................................................100 x 180 x 28 mm
Name tag dimensions: ....................................................................................................................48.5 x 15.5 mm
Tag and button light: ........................................................................................................................... White LEDs
Degree of protection of casings: ...................................................................................................................... IP55
Degree of protection from mechanical shocks: ................................................................................................IK07
Working temperature range: ............................................................................................................. -10 to +50° C
Max. humidity: ........................................................................................................................................... 95% RH
N.O. dry contact maximum current (OP3): ........................................................................................ 1 A @ 30 V
Transmitting capsule: .............................................................................................................electret microphone
Receiving capsule: ..................................................................................................16 Ω water-resistant speaker
Wires with cross-section area of 0.5 mm
section area smaller than 0.5 mm

11 KEY TO SYMBOLS

Symbol
~

12 SIMPLIFIED EU DECLARATION OF CONFORMITY

Hereby, URMET S.p.A. declares that the radio equipment types:
ONE- AND TWO-FAMILY 2-WIRE KIT WITH CALL FORWARDING FUNCTION
(Ref. 1723/95 and 1723/96) are in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address: www.urmet.com
DS1723-050B
2 or larger must comply with IEC 60332-1-2; wires with cross-
2
must comply with IEC 60332-2-2.
Direct input voltage
Alternating input voltage
Video door phone system trademark
Power supply fi tted with double insulator
DANGER - Presence of dangerous voltages
DANGER - Presence of safety-critical components
See the installation manual of the device
Description
