Urmet note 2 Manuel D'installation page 26

Video door phone Mod. VMODO Master
(qty. 1 in kit ref. 1723/95,
qty. 2 in kit ref. 1723/96)
Bracket for fi xing to wall
(qty. 1 in kit ref. 1723/95,
qty. 2 in kit ref. 1723/96)
Screws for fi xing to wall (ø 2.9 x 32 mm)
(qty. 4 in kit ref. 1723/95,
qty. 8 in kit ref. 1723/96)
Anchor bolts for fastening to wall (ø 5 mm)
(qty. 4 in kit ref. 1723/95,
qty. 8 in kit ref. 1723/96)
Screws for fi xing to fl ush-mounting box Mod. 503
Apartment (M3.5 x 19 mm)
station (qty. 2 in kit ref. 1723/95,
(B) qty. 4 in kit ref. 1723/96)
Lever for removing front panel from video door phone
(qty. 1 in kit ref. 1723/95,
qty. 2 in kit ref. 1723/96)
Six-pin wire for connecting optional devices
(qty. 1 in kit ref. 1723/95,
qty. 2 in kit ref. 1723/96)
Extractable terminal boards for connecting video door phone to
system
(qty. 2 in kit ref. 1723/95,
qty. 4 in kit ref. 1723/96)
Two-pin wire for connecting an optional temperature sensor
(qty. 1 in kit ref. 1723/95,
qty. 2 in kit ref. 1723/96)
System power supply unit
Power
supply unit
(C)
Audio video inductor
Video distributor
(D)
(only in kit ref. 1723/96)
26
1/2
1/2
4/8
4/8
2/4
1
1/2
2/4
1/2
1
1
1
