AGFA d-lab.3 Documentation Technique page 323

Printer • Printer • Tireuse
Transportwalze • Advance roller • Tambour de transport
3
N4037
Item no. D. Part no.
2 CM+ 8.8060.PE98.0
3 CM+7.0371.0115.0
4 CM+7.0327.3110.0
5 CM+7.0335.0101.0
6 CM+9.8060.PEJB.1
7 CM+7.8060.PERX.0
8 CM+7.0371.0115.0
9 CM+7.0371.0116.0
10 CM+8.8060.PE31.1
11 CM+7.0371.0039.0
AGFA d-lab.3
Description
Transportrolle
Transport roller
Cylindre de transport
Miniaturkugellager
Miniature ball bearing
Roulement à billes miniature
Scheibe
Washer
Rondelle
Druckfeder
Pressure spring
Ressort à pression
Riemenscheibe
Belt pulley
Poulie
Riemenscheibe unten
Pulley bottom
Poulie en bas
Miniaturkugellager
Miniature ball bearing
Roulement à billes miniature
Freilauf
Free-wheel
Axe libre
Spannblech, genietet
Tension plate, rivete
Tôle de tension, rivée
Kugellager
Grooved ball bearing
Roulement à billes
N4037
1-1
1-9
1-8
1-6
3
4
5
4
10
11
N4037
N0853
N5651
3 4
5
4
8
7
9
Remarks
20
MF148 2Z
8,1x12x0,5-St2 K40 Ni
HF 0812 KF
DIN625-688-ZZS INA
2002-06-01 / PN 0139_01
8.8060.PE34.2
1
1-7
1-5
1-4
1-3
1-2
N4037
2
6
N4037
N1564
12
N2300
N4037
8
N1564
PE02e
4.143
