AGFA d-lab.3 Documentation Technique page 171

Scanner • Scanner • Scanner
Cartridge Feeder • Cartridge Feeder • Introduction de cassettes
1
1-7
1-9
1-11
Item no. D. Part no.
1-10 CM+9.8506.9260.2
1-11 CM+9.8506.9590.0
1-12 CM+8.8506.8910.0
1-13 CM+7.8506.CFG5.1
AGFA d-lab.3
1-8
1-13
1-10
1-2
CF_GS01
Description
Gedruckte Schaltung (Power Distributor)
PCB (Power Distributor) assy
Circuit imprimé (Power Distributor)
SK-RISC Controller CF programmiert
RISC Controller CF programmed
SK-RISC contrôleur CF programmé
Gleichstromgetriebemotor
DC gear motor
Moteur d'engrenage CC
Taststift
Tracing pin
Palpeur
1-4
1-5
1-3
1-3
1-3
1-3
1-3
2002-06-01 / PN 0139_01
8.8508.CF02.0
1-6
1-6
1-1
CF_GS02
1-12
Remarks
2224-V024SR 4lB
IPI
CF02a
3.85
