Nobles Speed Scrub 2001HD Opérateur Manuel Et Liste Des Piéces page 99

SQUEEGEE CONTROL GROUP / GRUPO DE CONTROL DE LA ESCOBILLA DE GOMA /
REF PART # DESCRIPTION
1 160613 DHOSE, VACUUM, 1.5DX30L,
2- -CUFFS
2 1015636 DCABLE, SQUEEGEE LIFT
3 41169 NUT, HEX LOCK, .25- -20 NL SS
4 140236 SCREW, HEX, .50- -13X1.25 ZN
5 611480 SCREW, TRS, .50- -13X1.25 PHL SS
6 140045 WASHER, FLAT, 0.51B 1.25D .06 SS
7 140139 SLEEVE, P/M, 0.625D 0.500B 0.25L
STL PLT
8 02931 NUT, HEX LOCK .50- -13 NL SS
9 1021179 BRACKET, PIVOT, MOUNT,
SQUEEGEE
10 1011342 BRACKET, SQUEEGEE MOUNT
11 140509 NUT, 1/2- -13 HXJM SS
12 602981 SCREW, HEX, .50- -13X5.50 ZN
13 140024 WASHER, LOCK 0.50 SS
14 08712 NUT, HEX LOCK, M6X1.0 SS NL
15 15678 SCREW, HEX, M6X1.0X16 SS
RECOMMENDED STOCK ITEM / PIEZAS RECOMENDADAS EN ALMACÉN /
D
ELÉMENTS DE STOCK RECOMMANDÉS
Speed Scrub 2001HD (03- -05)
PARTS LIST - LISTA DE PIEZAS - LISTE DES PIÈCES
GROUPE COMMANDE DE RACLOIR
QTY.
1
1
2
1
1
6
2
1
1
1
2
1
2
1
1
REF PART # DESCRIPTION
16 611477 SPRING, SQUEEGEE
17 200031496 SCREW, M8X1.25X35
18 140015 WASHER, LOCK, SPLT, 0.31 SS
19 140027 WASHER, FLAT, 0.35B 0.75D .04 SS
20 602885 HANDLE, SQUEEGEE LIFT
21 200816 DGRIP, HANDLE .25 X 1 X 2.25
22 604358 SPACER BUSHING
23 230661 PLATE, LOCK CONTROL HOUSING
24 16931 SCREW, HEX, M8X1.25X20, 8.8
25 140268 SCREW, HEX, M5X0.8X12 SS
26 140031 WASHER, #10 EXT ZN
27 230712 PLATE, SQUEEGEE LOCK
28 1021007 PLATE, MOUNT (FaST MODEL)
29 630428 CLAMP, CABLE, STL, 1.0D X .50W, .25
MOUNT (FaST MODEL)
30 08712 NUT, HEX LOCK, M6X1.0 SS NL (FaST
MODEL)
31 15678 SCREW, HEX, M6X1.0X16 SS
(FaST MODEL)
QTY.
1
1
2
2
1
1
1
1
1
2
2
1
1
2
3
3
99
