Nobles Speed Scrub 2001HD Opérateur Manuel Et Liste Des Piéces page 79

SOLUTION TANK GROUP / GRUPE DEL DEPÓSITO DE DISOLUCIÓN /
REF PART # DESCRIPTION
1 608518 ASM., SOL. TANK LID GREEN
∇
2 612518 SOLUTION COVER, GREEN
Y
3 140706 RIVET, BLIND, .125D, PL
Y
4 611068 HINGE, .09 PIN .04 1.06W 6.5L
Y
5 603233 DECAL, BATTERY DIAGRAM
6 630010 DGASKET, 70 OD, 43 ID, 12.7 THK
7 630011 TUBE, VAC TRANS, FLANGE AND
BARB
8 630267 SPRING, CMPR, 59.9D 3.0W 50.8L
9 150529 FITTING, 3/4M X 3/4H BARB BRS
10 608706 VAC TRANS BRACKET
11 140027 WASHER, FLAT, 0.35B 0.75D .04 SS
12 140015 WASHER, LOCK, SPLT, 0.31 SS
13 16931 SCREW, HEX, M8X1.25X20, 8.8
14 1012965 DCAP, PORT, SOLUTION FILL
15 01683 WASHER, FLAT, #10 SS
16 1018155 SCREW, PAN, M4.8X16 SS TCUT
17 16931 SCREW, HEX, M8X1.25X20, 8.8
18 230925 SUPPORT, RECOVERY TANK
19 611418 SLEEVE, P/M 0.437D, 0.315B, 0.14L
20 140032 WASHER, #6 FLAT SS
21 600650 LABEL, CE, SQUEEGEE LEVER
22 1023712 KIT, TANK, SOLUTION, GREEN
(Before SN 10227906)
1023348 TANK, SOLUTION, GREEN
(After SN 10227906)
23 607983 HOSE, DRAIN W/LEVEL IND.
24 602529 DFILTER, SCREEN, SOLUTION FILL
25 608915 CLAMP, HOSE, WIRE 1.03- -1.09
ASSEMBLY / CONJUNTO / ENSEMBLE
∇
INCLUDED IN ASSEMBLY / INCLUIDO A CONJUNTA / Y COMPRIS EN
Y
ENSEMBLE
RECOMMENDED STOCK ITEM / PIEZAS RECOMENDADAS EN ALMACÉN /
D
ELÉMENTS DE STOCK RECOMMANDÉS
Speed Scrub 2001HD (06- -06)
PARTS LIST - LISTA DE PIEZAS - LISTE DES PIÈCES
ENSEMBLE DU RÉSERVOIR DE SOLUTION
QTY.
1
1
7
1
1
1
1
1
2
1
3
3
2
1
1
1
1
1
1
2
1
1
1
1
1
1
REF PART # DESCRIPTION
26 630016 RING, RETAINING, EXT, 1.82D
27 608451 DECAL, "SPEED SCRUB 2001HD"
614367 DECAL, "SPEED SCRUB 2001HD
FaST"
28 1029695 DCASTER, 4.0D X 1.38W
29 140027 WASHER, FLAT, 0.35B 0.75D .04 SS
30 140015 WASHER, LOCK, SPLT, 0.31 SS
31 578237000 SCREW, HEX, M8X1.25X18 SS, 933
32 1026454 SCREW, PAN, M5X0.8X10, SS
33 07514 WASHER, LOCK, INT #10 SS
34 612765 SHIELD, LIGHT
35 613455 GASKET, 1/2"X1.34'
36 1024583 LIGHT, SAFETY, 12"
37 608184 LABEL, NOBLES LOGO
38 3701.6 SCREW, PAN, #6- -32X0.38, PHL SS
39 613733 LABEL, ATTENTION (FaST MODEL)
40 578301 DKNOB, RND
41 140826 SCREW, PAN, #6- -32X0.75, PHL SS
42 621443 DCHAIN, BALL, #10X157L, SS
43 605061 DCOVER, SOLUTON FILL
44 605062 DGASKET, COVER, SOLUTION FILL
45 07514 WASHER, LOCK, INT, #10 SS
46 578201000 SCREW, PAN, #10- -32X0.50, PHL
47 606146 DFILTER, SCREEN, SOL- -FILL
48 140032 WASHER, #6 FLAT
49 140826 SCREW, PAN, #6- -32X0.75, PHL SS
50 1020193 SHIELD, LIGHT
51 19324 WASHER, FLAT, #10 SAE
52 604930 SCREW, TRS, M5X0.8X10, PHL, ZN
53 613454 GASKET, .50X.50X1.17 CLSD CELL
QTY.
1
2
2
2
8
8
8
2
2
1
2
1
1
2
1
1
1
1
1
1
1
1
1
2
2
1
2
2
1
