4 Electrical installation
Wiring of the control connections

Technical data

4.7.6 Technical data
Safety relay K
Terminal Description
X11/K32 Safety relay K
SR
X11/K31 1st disconnecting path
X11/33
X11/34
Digital inputs, digital outputs
Terminal Description
X5/28 Controller inhibit
(DCTRL-CINH)
2nd disconnecting path
X5/E1 Digital inputs
X5/E2
X5/E3
X5/E4
X5/E5
X5/A1 Digital outputs
X5/A2
X5/A3
X5/A4
X5/39 GND2
X5/59 Connection of external
voltage source for backup
operation of the drive
controller in the case of
mains failure
X5/ST1 STATE-BUS
X5/ST2
182
SR
Field
Coil voltage at +20 °C
Coil resistance at +20 °C
Rated coil power
Max. switching voltage
Max. AC switching capacity
Max. switching current (ohmic load)
Recommended minimum load
Max. switching rate
Mechanical service life
Electrical service life
at 250 V AC
(ohmic load)
at DC 24 V
(ohmic load)
Field
PLC level, HTL
PLC level, HTL
Input current per input
Cycle time
PLC level, HTL
Load capacity per output
Load resistance
Cycle time
Reference potential for digital signals
Isolated to X6/7 (GND1)
Input voltage
Current consumption
Maximum number of nodes
Maximum length of the bus cable

Values
DC 24 V (20 ... 30 V)
823 Ω ±10 %
Approx. 700 mW
AC 250 V, DC 250 V (0.45 A)
1500 VA
AC 6 A (250 V), DC 6 A (50 V)
> 50 mW
6 switchings per minute
7
10 switching cycles
5
10 switching cycle at 6 A
6
10 switching cycles at 1 A
7
10 switching cycles at 0.25 A
3
6 × 10 switching cycles at 6 A
6
10 switching cycles at 3 A
6
1.5 × 10 switching cycles at 1 A
7
10 switching cycles at 0.1 A
Values
LOW: 0 ... +3 V
HIGH: +12 ... +30 V
h t t p : / / w w w . D a t a S h e e t 4 U . n e t /
LOW: 0 ... +3 V
HIGH: +12 ... +30 V
8 mA for +24 V
1 ms
LOW: 0 ... +3 V
HIGH: +12 ... +30 V
Maximally 50 mA
For +24 V 480
1 ms
DC 24 V (+18 ... +30 V)
Maximally 1 A for 24 V
20
5 m
at a minimum
Ω
EDKVS9332X DE/EN/FR 2.0
