Operating Elements And Connections; Safety Notes; Applications - IMG STAGELINE TRIPLE SCAN Mode D'emploi

All operating elements and connections can be
GB
found on the fold-out page 3.
1 Operating Elements
and Connections
1 LED display to show the menu settings, press a
button (2) to activate it
2 Operating buttons to adjust the unit via the sys-
tem menu
3 Control input (3-pole XLR chassis plug)
4 Control output (3-pole XLR jack)
5 Microphone for music control
6 Mounting bracket
7 Locking screws for the mounting bracket (6)
8 Mains jack for connection to a socket (230 V~ /
50 Hz) via the supplied mains cable; at the jack,
the support for the mains fuse is provided (only
replace a blown fuse by one of the same type)
9 Safety lug for fixing a safety rope

2 Safety Notes

The unit corresponds to all required directives of
the EU and is therefore marked with
WARNING The unit is supplied with hazardous
mains voltage. Leave servicing to
skilled personnel only. Do not insert
anything into the air vents! Inexpert
handling or modification of the unit
may cause an electric shock hazard.
It is essential to observe the following items:
G
The unit is suitable for indoor use only. Protect it
against dripping water and splash water, high air
humidity and heat (admissible ambient tempera-
ture range 0 – 40 °C).
G
Do not place any vessels filled with liquid, e. g.
drinking glasses, on the unit.
G
Do not set the unit into operation, or immediately
disconnect the mains plug from the mains socket if
1. there is visible damage to the unit or to the
mains cable,
2. a defect might have occurred after a drop or
similar accident,
3. malfunctions occur.
The unit must in any case be repaired by skilled
personnel.
G
Never pull the mains cable to disconnect the
mains plug from the mains socket, always seize
the plug.
G
No guarantee claims for the unit and no liability
for any resulting personal damage or material
10
chapter 5.1
damage will be accepted if the unit is used for
other purposes than originally intended, if it is not
safely mounted or not correctly operated, or not
repaired in an expert way.
G
Important for U. K. Customers!
The wires in this mains lead are coloured in ac -
cord ance with the following code:
green/yellow = earth
blue = neutral
brown = live
As the colours of the wires in the mains lead of
this appliance may not correspond with the
coloured markings identifying the terminals in
your plug, proceed as follows:
1. The wire which is coloured green and yellow
must be connected to the terminal in the plug
which is marked with the letter E or by the earth
symbol , or coloured green or green and yel-
low.
2. The wire which is coloured blue must be con-
nected to the terminal which is marked with the
letter N or coloured black.
3. The wire which is coloured brown must be con-
nected to the terminal which is marked with the
letter L or coloured red.
Warning – This appliance must be earthed.
.

3 Applications

This light effect unit is suitable for applications on
stage, in discothèques, clubs and party rooms. It is
equipped with 78 super bright LEDs creating
changing patterns of points lighting in blue, red and
green. The patterns are projected via three mov-
able mirrors on the illuminated area, this provides a
room-filling light effect.
The light effect unit is designed for control via a
DMX light controller (4 or 8 DMX channels for
selection). However, it can also be operated with-
out a controller, either as an individual unit or inter-
connected with several LED-300RGB units in the
master / slave mode.
4 Mounting
G
Always place the unit in such a way that a suffi-
cient air circulation will be ensured during opera-
tion. Never cover the air vents at the housing
(e. g. by curtains).
G
The minimum distance to the illuminated area
should be 50 cm.
If the unit is to be put out of operation
definitively, take it to a local recycling plant
for a disposal which is not harmful to the
environment.
