To brighten the camera image, you can adjust the brightness or the black and white con-
trast. This adjustment can be set to one of four levels (100 %, black and white contrast,
0 %, 50 %).
Press the (6) button repeatedly until the required brightness level has been reached or
the black and white contrast has been set.
Note: The set brightness is 100 % for black and white contrast.
Do not look directly into the light (11) and do not direct the light onto other
u
people. The light can blind your eyes.
To reduce brightness and switch off the camera light (11), press the (6) button re-
peatedly until the required brightness level has been reached or the light has been
switched off.
Magnifying the image in the display (zooming in)
Briefly pressing the magnification button (5) magnifies the image in the display by a
factor of 1.5 or 2.
Rotating the Image on the Display
The (3) button rotates the image on the display through 180°.
Transferring Images
It is possible to transfer images by inserting a micro SD card (19) in FAT32 format. When
the formatted micro SD card (19) is inserted, all images are automatically transferred
from the local memory to the micro SD card (19) and deleted from the local memory.
Inserting the Micro SD Card
Only use micro SD cards between 4 GB and 32 GB which support FAT32 format.
If necessary, format the micro SD card (19) in FAT32 format before inserting it.
Insert the formatted micro SD card (19) all the way into the slot (18).

Working Advice

Check the environment that you want to inspect, paying particular attention to obstacles
or hazardous areas.
Bend the camera cable (8) so that the camera head can be easily introduced into the en-
vironment to be inspected. Carefully introduce the camera cable.
Adjust the brightness of the camera illumination light (11) so that the image is easily re-
cognisable. When photographing highly reflective objects, for example, you can achieve
better results in lower light or using black and white contrast setting.
If objects to be inspected look blurred, then reduce or increase the distance between
camera head (10) and object.
