10 | English
Rotating platform
Weight according to EPTA-Proced-
ure 01:2014
Protection rating
A) Only non-conductive deposits occur, whereby occasional tem-
porary conductivity caused by condensation is expected.
For clear identification of your rotating platform, see the serial
number (11) on the type plate.
Remote control
Article number
A)
Working range
Operating temperature
Storage temperature
Max. altitude
Relative air humidity max.
Pollution degree according to
IEC 61010-1
Batteries
Weight according to EPTA-Proced-
ure 01:2014
A) The working range may be reduced by unfavourable environ-
mental conditions (e.g. direct sunlight).
B) Only non-conductive deposits occur, whereby occasional tem-
porary conductivity caused by condensation is expected.
For clear identification of your remote control, see the serial
number (25) on the type plate.
Assembly
Rotating Platform Power Supply
The rotating platform is powered by the mounted measuring
tool.
Remote Control Power Supply
Using alkali-manganese batteries is recommended to oper-
ate the remote control.
To open the battery compartment cover (23), press on the
locking mechanism (24) and remove the battery compart-
ment cover. Insert the batteries.
When inserting the batteries, ensure that the polarity is cor-
rect according to the illustration on the inside of the battery
compartment.
Always replace all the batteries at the same time. Only use
batteries from the same manufacturer and which have the
same capacity.
Remove the batteries from the remote control when
u
not using it for longer periods. The batteries can cor-
rode and self-discharge during prolonged storage in the
remote control.
1 609 92A 73S | (27.01.2022)
Mount the measuring tool on the rotating
RM 3
platform (see figure A)
0.46 kg
Place the measuring tool with the guide groove (15) on the
guide rail (4) of the rotating platform (6) and slide the meas-
IP54 (dust and
uring tool as far as it will go onto the platform.
splash-proof)
To disconnect the measuring tool, pull it off the rotating plat-
form in the opposite direction.
Roughly align the rotating platform horizontally using the
height adjustment screws (7).
RC 2
Mount the holder and BM 3 ceiling clip
3 601 K69 C..
(see figure B)
20 m
Insert the holder (13) into rails on the bottom of the rotating
–10 °C to +50 °C
platform until you hear it click into place. Pull the holder out
–20 °C to +70 °C
of the rotating platform to remove it.
2000 m
You can use the magnets of the mounted holder (13) to at-
tach the rotating platform to the ceiling clip (14).
90 %
Keep your fingers away from the rear side of the mag-
u
B)
2
netic accessory while attaching the accessory to sur-
faces. The strong pulling force of the magnets may jam
3 × 1.5 V
your fingers.
LR3 (AAA)
0.05 kg Rotating Platform Positioning Options
(see figure C)
You can use the rotating platform as follows:
– Standing on a flat surface,
– With the holder (13) screwed onto a vertical surface,
– With the holder (13) and ceiling clip (14) attached to
crown mouldings,
– With the holder (13) attached to magnetisable materials,
– With the 1/4" tripod mount (10) screwed onto a commer-
cially available 1/4" tripod (not shown).
Keep your fingers away from the rear side of the mag-
u
netic accessory while attaching the accessory to sur-
faces. The strong pulling force of the magnets may jam
your fingers.
Operation
Protect the rotating platform and remote control
u
against moisture and direct sunlight.
Do not expose the rotating platform or remote control
u
to any extreme temperatures or variations in temper-
ature. For example, do not leave them in a car for exten-
ded periods of time. In case of large variations in temper-
ature, allow the rotating platform and the remote control
to adjust to the ambient temperature before putting them
into operation.
Starting Operation of the Rotating Platform
Once a measuring tool has been switched on and has suffi-
cient voltage, the measuring tool connection indicator (1)
will light up and the rotating platform will be ready for opera-
tion.
The rotating platform cannot be used without a measuring
tool.
