Replacing The Bulb - Oase Profilux Led Mode D'emploi

- GB -
Pos: 46 /Lampen/Wasserspieltechnik/Profilux LED/Auswechseln des Leuchtmittels Profilux LED @ 10\mod_1246283491434_121.doc @ 63960 @

Replacing the bulb (1)

Adhere to the safety instructions! Disconnect the power! Undo the screw-connection of the top section. Ensure that no
moisture can enter the unit. Remove and clean the top and the glass. Disconnect the plug connector and (open the
large bracket on the flat side of the plug [3]) remove the bulb. Important! Only original bulbs from OASE may be used.
Insert the new bulb. Note that the recess at the outside of the retaining ring is inserted via the housing web. Check the
gasket and replace, if damaged. Reassemble the unit in the reverse order, connect to the power supply and perform a
function check.
Pos: 47 /Lampen/Wasserspieltechnik/Lunaqua 35/Reinigung Lunqua 35 @ 4\mod_1154519461544_121.doc @ 22379 @
Cleaning
Adhere to the safety instructions! Carry out the work steps as specified under 'Replacing the bulbs'. Only use water
and a soft brush. Ensure that no moisture can enter the unit.
Pos: 48 /Alle Produkte/Entsorgung - gem. Bestimmungen/Fachhändler @ 0\mod_1125578523312_121.doc @ 1407 @
Disposal
Dispose of the unit in accordance with the national legal regulations.
Pos: 49 /Lampen/Wasserspieltechnik/Lunaqua 10 LED/Störungen Lunaqua 10 LED @ 10\mod_1242636103935_121.doc @ 62681 @
S
Malfunctions
Malfunction
Lamp does not light up
Light intensity decreases
Water in the spotlight housing
Pos: 50 /Alle Produkte/Dummy_module/===== Seitenwechsel ===== @ 0\mod_1125648978015_0.doc @ 1630 @
8
Cause
Power supply interrupted
Bulb defective
Lamp glass soiled
Seal defective
Remedy
Check power supply
Replace bulb
Clean
Check sealing rings and replace, if necessary
