Operating Instructions SATA HRS
EN
Physical damage from incorrect cleaning
The pressurized cup spray gun can be damaged if immersed in solvent
or cleaning agent or if cleaned in an ultrasonic cleaning machine.
→ Do not place the pressurized cup spray gun in solvent or cleaning
agent.
→ Do not clean the pressurized cup spray gun in an ultrasonic cleaning
machine.
■ Unscrew the pressurized cup [1-4] / [1-7] / [1-13]; in doing so, the pres-
surized cup spray gun is also vented at the cup thread.
■ Fill the pressurized cup with a suitable cleaning agent and screw onto
the pressurized cup spray gun.
■ Shake the pressurized cup spray gun thoroughly.
■ Spray the cleaning agent out of the pressurized cup spray gun through
the connected wand at the quick coupling [1-15] until clean and wipe
the outside with a cloth soaked in cleaning agent or with a cleaning
brush.
■ Blow the pressurized cup spray gun dry.
12.3. Clean the check valve
If the check valve [1-18] doesn't work, it must be removed and cleaned.
■ Remove the check valve [1-18] (see chapter 11.2).
■ Clean the spring [2-2] and ball [2-3] thoroughly with a suitable cleaning
agent.
■ Coat the spring and ball with SATA high performance grease (Art. No.
48173).
■ Mount the check valve (see chapter 11.2).
12.4. Clean the inlet valve
■ Unscrew the pressurized cup [1-4] / [1-7] / [1-13]; in doing so, the pres-
surized cup spray gun is also vented at the cup thread.
■ Unscrew the inlet valve [3-8] out of the gun body [3-9].
■ Clean the inlet valve with a cloth soaked in cleaning agent or with a
cleaning brush.
■ Blow the inlet valve dry.
■ Screw the inlet valve into the gun body.
