Key To The Wiring Diagram; Technical Characteristics - Mase Generators IS 9000 Manuel D'instructions Et D'entretien

mase
MOTOR
Model
Displacement
Revs
Bore x stroke
Power
Fuel consumption
Fuel type
Starter system
Oil capacity
Maximum inclination
ALTERNATOR
Model
Continuous power
Power factor
Insulation class
Frequency
Key to the wiring diagram (page 5)
1 Remote control panel
2 Stator
3 Rotor
4 Alternator thermostat
5 Battery charger regulator (B.C.)
6 Stop solenoid valve
7 Starter motor
8 Pre-heating glow plugs
9 Fuses
10 Battery
11 Relay card
12 Oil pressure gauge
13 Motor and water thermostats
14 Automatic voltage regulator (A.V.R.)
15 Power terminals
GB

6 TECHNICAL CHARACTERISTICS

3-cylinder explosion engine — 4-stroke
in
3
r.p.m.
in
Hp
g/Hp/h
US qt
Syncronous — single phase — self-excited
W
(cos φ)
Hz
23
IS 9000 IS 9500
Yanmar 3TN66
diesel — water cooled
40.2
3000
26 x 25.3
13
180
Diesel
Electric, 12 V
4.0
30°
two poles — A.V.R.
7600
1
F
50
IS 9000 - 9500
3600
15
185
8500
60
