To Install the Battery Pack into the Tool Handle
1. Align the battery pack 1 with the rails inside the tool's
handle (Fig. C).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap into place.
To Remove the Battery Pack from the Tool
1. Press the release button 2
out of the tool handle.
2. Insert battery pack into the charger as described in the
charger section of this manual.
Fuel Gauge Battery Packs (Fig. A)
Some D WALT battery packs include a fuel gauge which
e
consists of three green LED lights that indicate the level of
charge remaining in the battery pack.
To actuate the fuel gauge, press and hold the fuel gauge button.
A combination of the three green LED lights will illuminate
designating the level of charge left. When the level of charge
in the battery is below the usable limit, the fuel gauge will not
illuminate and the battery will need to be recharged.
nOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-user application.
Belt Hook and Magnetic Bit Holder (Fig. A)
(Included with some models)

WARNING: To reduce the risk of serious personal
injury, DO NOT suspend tool overhead or suspend
objects from the belt hook. ONLY hang tool's belt hook
from a work belt.

WARNING: To reduce the risk of serious personal
injury, ensure the screw holding the belt hook is secure.
IMPORTanT: When attaching or replacing a belt hook or
magnetic bit holder, use only the screw that is provided. Be sure
to securely tighten the screw.
A belt hook 9 and magnetic bit holder
to either side of the tool using only the screw
to accommodate left- or right-handed users. If the hook or
magnetic bit holder is not desired at all, it can be removed from
the tool.
To move the belt hook or magnetic bit holder, remove the
screw 10 that holds it in place then reassemble on the opposite
side. Be sure to securely tighten the screw.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicable regulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
and firmly pull the battery pack
11 can be be attached
10 provided,
Proper Hand Position (Fig. D)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
sudden reaction.
Proper hand position requires one hand on the main handle
Variable Speed Trigger Switch (Fig. A, E)
To turn the tool on, squeeze the trigger switch
the tool off, release the trigger switch. Your tool is equipped
with a brake. The chuck will stop when the trigger switch is
fully released.
The variable speed switch enables you to start the application at
a slow speed. The further you squeeze the trigger, the faster the
tool will operate. For maximum tool life, use variable speed only
for starting holes or fasteners.
nOTE: Continuous use in variable speed range is not
recommended. It may damage the switch and should
be avoided.
Forward/Reverse Control Button (Fig. A, E)
A forward/reverse control button
the tool and also serves as a lock-off button.
To select forward rotation, release the trigger switch and
depress the forward/reverse control button on the right side of
the tool.
To select reverse, depress the forward/reverse control button on
the left side of the tool. The centre position of the control button
locks the tool in the off position. When changing the position of
the control button, be sure the trigger is released.
nOTE: The first time the tool is run after changing the direction
of rotation, you may hear a click on start up. This is normal and
does not indicate a problem.
Worklights (Fig. A)
There are three worklights 7 located around the 6.35 mm hex
chuck 6 . The worklights are activated when the trigger switch
is depressed.
When the trigger is released, the worklight will stay illuminated
for up to 20 seconds. If the trigger switch remains depressed,
the worklights will remain on.
nOTE: The worklights are for lighting the immediate work
surface and are not intended to be used as a flashlight.
Quick-Release Chuck (Fig. A, F, G)

WARNING: Use only impact accessories. Non-impact
accessories may break and cause a hazardous condition.
Inspect accessory prior to use to ensure that it con tains
no cracks.
nOTE: The chuck accepts 6.35 mm hex bit tips only. Using
25 mm bits allows better access in tight spaces.
Place the forward/reverse button
position or remove battery pack before changing accessories.
