Adjustment item
Menu display
Line display
Keystone
PC2 (BNC)
Right Left rev.
Top Bottom inv.
RS-232C [bps]
Sleep time [min]
* Factory set value
5
Press the ESCAPE button to return to the previous menu or press the MENU button
to exit the menu mode.
Note
• Refer to "Removing the Trapezoidal Distortion of the Image" on page 34 for more details about adjusting the keystone.
CAUTION
• Correctly set the "PC2 (BNC)" according to the device connected to the PC2 terminals. However, when the PC signal is
input, RGB input is used irrespective of which setting (YP
Button
Sets whether to clear the menu display automatically or not.
2 or 3
15sec* : Clears the display automatically in about 15 seconds.
ON : Does not automatically clear the menu display.
Sets whether to show the line display (Y/C, VIDEO, PC1, or PC2) on top right of the
screen or not when the VIDEO or PC button is pressed.
2 or 3
5sec* : Shows the line display for about 5 seconds.
OFF : Does not show the line display.
Press the ENTER button to enter the keystone submenu.
In the keystone submenu, press 2 or 3 to correct trapezoidal distortion of the
projected image. (–80 ↔ 0* ↔ +128)
ENTER To reset the keystone (trapezoidal distortion of the picture image) to the original
setting (factory set value: 0), press the PRESET button when the "Keystone"
submenu appears on the screen.
To exit the keystone submenu, press the ESCAPE button.
Sets the input signal source according to the device connected to the PC 2 terminals.
However, the input will be RGB irrespective of the PC signal setting.
2 or 3
RGB* : For a device with analog RGB, V, H/Cs signals
YP P : For a device with component (Y, B-Y, R-Y) or DTV-format (Y, P
B R
signals
Reverses image right-to-left.
2 or 3
OFF* : For the front method.
ON : For upside-down hanging from the ceiling.
Inverses image upside-down.
2 or 3
OFF* : For normal setup.
ON : For upside-down hanging from the ceiling.
Sets the baud rate for transmission.
2 or 3
9600 : 9600 bps
19200* : 19200 bps
Sets the length of sleep time which automatically brings the projector into stand-by
2 or 3
state. You can select one of the sleep times: 15, 30, 60 and 0 (OFF*) minutes.
