I Allowable input signals
Signal
PC system PC98
PC/AT
DOS/V
Mac
Video system Video
* : Only for DLA-M2000SCU
Notes
• The resolution for the input signals is listed in the above table.
• Even signals in the frequency range that can be input may not be displayed normally depending on the type of the signal.
• When a signal other than listed above is input, the image could be partially erased or an unneeded fold-over image could
appear.
• Some signals other than listed above can be displayed. But they may require adjustment.
• Even some of the signals listed above may require adjustment depending on the video board used.
• Composite sync (C ) and G on Sync signals cannot be handled depending on the devices connected.
S
• The VGA signal of the PC system could be displayed in 480p mode of the VIDEO system. (In this case, the projector enters
video menu mode when the MENU button is pressed.)
Horizontal
resolution
Hor [Pixels]
VESA350
PC98
VGA 60Hz
VGA 72Hz
VGA 75Hz
VGA 85Hz
SVGA 56Hz
SVGA 60Hz
SVGA 72Hz
SVGA 75Hz
SVGA 85Hz
XGA 43Hz
XGA 60Hz
XGA 70Hz
XGA 75Hz
XGA 85Hz
SXGA 43Hz
SXGA 60Hz
SXGA 75Hz
SXGA 85Hz
UXGA 60Hz
MAC13
MAC16
MAC19
MAC21
HDTV (1035i) 60Hz
HDTV (1035i) 59Hz
480p
720p 60Hz
720p 59Hz
1080i 60Hz
1080i 59Hz
1080 24sF*
NTSC
PAL
SECAM
DLA-M2000LU/M2000SCU/ LCT0940-002A / ENGLISH
Connecting to Various Devices
Vertical Horizontal
resolution frequency
Ver [Lines] H [kHz]
640 350
640 400
640 480
640 480
640 480
640 480
800 600
800 600
800 600
800 600
800 600
1024 768/2
1024 768
1024 768
1024 768
1024 768
1280 1024/2
1280 1024
1280 1024
1280 1024
1600 1200
640 480
832 624
1024 768
1152 870
720 483
1280 720
1280 720
1920 1080/2
1920 1080/2
1920 1080
Vertical
frequency
V [Hz]
37.86 84.13
24.83 56.42
31.47 59.94
37.86 72.81
37.50 75.00
43.27 85.01
35.16 56.25
37.88 60.32
48.08 72.19
46.88 75.00
53.67 85.06
35.52 43.48
48.36 60.00
56.48 70.07
60.02 75.03
68.68 85.00
46.43 43.44
63.98 60.02
79.98 75.03
91.15 85.02
75.00 60.00
35.00 66.67
49.73 74.55
60.24 74.93
68.68 75.06
33.75 60.00
33.72 59.94
31.47 59.94
45.00 60.00
44.96 59.94
33.75 60.00
33.72 59.94
27.00 24.00
15.734 60
15.625 50
15.625 50
23
