OIL FILTER ELEMENT, WATER PUMP AND RIGHT CRANKCASE COVER

OIL FILTER ELEMENT, WATER PUMP AND RIGHT CRANKCASE COVER
Extent of removal:
Extent of removal
Preparation for removal
1 3
1 Oil filter element removal
3 Right crankcase cover removal
Order Part name
OIL FILTER ELEMENT, WATER PUMP
AND RIGHT CRANKCASE COVER
REMOVAL
Drain the engine oil.
Drain the coolant.
Radiator hose 3
Exhaust pipe
Brake pedal
Right engine guard
1 Oil filter element cover
2 Oil filter element
2 Water pump removal
Q'ty
Refer to "ENGINE OIL REPLACEMENT" section in
the CHAPTER 3.
Refer to "COOLANT REPLACEMENT" section in the
CHAPTER 3.
Disconnect at water pump side.
Refer to "EXHAUST PIPE AND SILENCER" section.
Refer to "ENGINE REMOVAL" section.
1
1
4 - 135
ENG
Remarks
