AGFA MSC 100.d Documentation Technique page 295

MSC 101: Hauptrahmen • Main body block • Châssis principal • 6/12
3
1
1-2
1-11
1-8
1-1
1-1
1-10
Item no. D. Part no.
1 CL+P5A-87480
z
1-1 CL+P4A-E5043
z
1-2 CL+P3-87442
z
1-3 CL+P5A-E8372
1-3-1 CL+P4-73981
z
1-4 CL+P4-87448
z
1-5 CL+P4-87453
1-6 CL+P4-5915
z
1-7 CL+P4-5506(5/1)
1-8 CL+P4-5942(2/1)
4.16
2001-05-01 / PN 0113
1-5
1-7
1-3-1
1-6
1-9
1-4
1-11
1-3
Description
Abdeckung
Cover assy
Revêtement
Platte vollständig
Plate assy
Plaque complet
Platte
Plate
Plaque
Tür
Door assy
Volet
Lichtdichtung
Shield (light)
Cache lumiere
Winkel
Bracket
Equerre
Verriegelungsbügel
Lock bracket
Etrier de verrouillage
Drehgriff
Handle
Poignée
Scharnier
Hinge
Charnière
Stöpsel
Grommet
Broche
Papierlauf • Paper advance • Avance papier
2
6
4
4-6
4-3
4-5 4-4
4-8
4-7
Remarks
A-88
TH-TM-No. 11
AGFA MSC 100.d, 101.d
5
4-1
4-2
A0557e
