3.4 Transporting the Compressor

WARNING!
– NEVER transport a compressor with a cylinder
connected to or stored on the compressor, otherwise
injury or damage can occur.
CAUTION!
– When transporting the compressor, be careful not
to bump the compressor or the connectors into
obstacles. Otherwise, damage to the compressor may
occur.
1. There are two methods to safely transport the compressor:
•
One Hand ‐ Grasp the hand grip A at the bottom rear of
the compressor.
• Two Hands ‐ Grasp the hand grips B on the sides of
compressor.
1195663-A

3.5 Installing the Power Cord

1. Choose a proper location. Refer to Choosing a Location in this
section of the manual.
2. Make sure the power switch is in the Off (O) position.
Plug the power cord into the electric connector A in the back
3.
of the compressor B.
Plug the opposite end of the power cord C into the wall outlet
4.
D.
5. Leave a minimum of 3 in (7.6 cm) clearance to the power cord
ends for disconnection access.
The power inlet acts as the mains disconnection device
to remove all power to the unit when the line cord is
disconnected.
Setup
15
