Apartment With Telephone - golmar VistaPlus Manuel D'installation

140
A
partment with telephone.
If an apartment does not desire a video system monitor, then a T-730/R5 telephone can be
installed using just 3 wires.
monitor needs to be installed in the future.
The total number of elements per apartment (monitors, telephones, call repeaters,
REMEMBER:
etc.) must never exceed two units.
With D4L-R5 distributor
Tekna R5
R. Line
_ _
+
Vi+ Vi-
With D4L-R5R distributor
Tekna R5
R. Linea
_ _
+
Vi+ Vi-
It is recommended not to cut the 2 extra wires in case a
M
JP1
+
A/D
SA
VD1+
VD1-
_
+
D/A
VD2+
VD2-
_
+
D/A
JP1
M
_
+
A/D SA
Vout
+
+
_
_
+
A/D
OPTIONAL CONNECTIONS
To the next floor
D4L-R5
D/A
OUTPUT
VD4-
CN2
VD4+
D/A
CN1
INPUT
VD3-
VD3+
From the previous floor
To the next floor
D4L-R5R
+
+
Vin
_
Junction Box
From the previous floor

Apartment with telephone

T-730/R5
M
+ A/D SA
Apartment with telephone
T-730/R5
M
+
A/D SA
_
+
A/D
M
= Master.
= Slave.
S
