FLEX POWER II
CABLE ASSEMBLY IN EVAPORATOR
Leave the cable at the required length, secure
4
the terminals and insert them in a 4-way box
so the colours match the evaporator box,
and connect to it.
MALE EVAPORATOR HOLDER
4
VIEW OF WHERE THE TERMINALS
ARE INTRODUCED
V/V
V
N
R
FEMALE CABLE HOLDER
4
VIEW OF WHERE THE TERMINALS
ARE INTRODUCED
31
M
V
R
V
