3.2 Installation
CAUTION
!
When assembling, disassembling or preparing the X-cal 2000 breath alcohol simulator
for use, ensure that it is not plugged into an electrical outlet.
Hot surface – avoid contact with the heating element.
Never connect the simulator to an electrical outlet without first adding solution and at-
taching the top housing.
The X-cal 2000 breath alcohol simulator is intended for authorized technicians only.

Before use, check that the simulator power supply rating (24VDC, 2.5A) conforms to local

supply ratings.
Do not expose the simulator to direct sunlight for extended periods of time.

Do not use the simulator with any toxic or flammable liquids, or in explosive atmospheres.

Do not use the simulator in explosive atmospheres.

Recommended: use the simulator within room temperature environments (23 °C ± 5 °C).

The solution container, tubing and mouthpieces must be completely dry; even slight con-

densation may disrupt calibration.
Fit tubing or mouthpieces on an aquarium air pump or a similar setup for drying.

The simulator requires 500 mL of solution; the fill line is marked on the simulator container

Do not under or over fill the simulator container.

Do not over tighten the top housing.

Connect the simulator cables neatly to ensure simple disconnection after use.

To install the X-cal 2000:
1. Place the X-cal 2000 simulator on a flat surface, free from obstruction.
2. With the X-cal 2000 breath alcohol simulator power disconnected, turn the top housing
counter clockwise (left) and detach it from the container.
3. Add the entire contents of the 500 mL bottle of alcohol reference solution into the X-cal 2000
solution container.
The bottle contains the exact liquid volume required for calibration, which is also marked on
the X-cal 2000 container.
4. Return the top housing onto the container, be careful not to over tighten.
5. Connect tubing with the round mouthpiece to the X-cal 2000 simulator air inlet and tubing
with the liquid trap mouthpiece to the air outlet.
6. Connect tubing with the liquid trap mouthpiece to the X-cal 2000 simulator air outlet.
7. Perform a leak check by covering the air outlet tube with your thumb and blowing into the
air inlet tube.
Air bubbles should not appear in the solution. In case of bubbling, check that the X-cal 2000
head is tightened properly. Return the X-cal 2000 to an authorized service provider if the
problem persists.
8. Connect the power cable to the simulator power input and to a wall outlet.
