Connections

Example of system configuration

Genlock signal generator
Cable compensation
unit
AW-RC400
Colour monitor
(75j terminator)
Video signal
System TALLY
Switcher, special
effects generator,
etc.
AC adapter:
AW-PS300A
Video signal
G/L signal
Pan/tilt head/camera control signal
Multi Hybrid control panel
AC adapter:
AW-PS505A
22 (E)
Halogen lamp
Coaxial cable
(BBC No.PSF1/2M, BELDEN 8281)
Coaxial cable
(BBC No.PSF1/2M, BELDEN 8281)
AW-RP555
Pan/tilt head
system
10BASE-T
AC adapter:
AW-PS505A
