How to change the position of the connector panel

The position of the connector panel can be changed from the rear panel to the bottom
panel.
K Before changing the position, turn off the power.
Remove the four bottom panel screws, and
remove the blank panel.
Remove the four rear panel screws, and
remove the connector panel.
Secure the blank panel to the rear panel
using the screws.
Remove the two rubber feet from the blank
panel.
Secure the connector panel to the bottom
panel using the screws.
Remove the blank panel.
Remove the
connector panel.
Blank panel
Connector panel
39 (E)
ScrewsV4
(bottom panel)
ScrewsV4 (rear panel)
ScrewsV4 (rear panel)
Remove the two rubber feet.
ScrewsV4 (bottom panel)
