correct, the decoded information is displayed, and the "Start ?" message indicates that the device is ready
to start welding.

5.11.2 Entering Voltage and Time

If the "Enter Voltage/Time" option was chosen in the manual input menu, "Enter PIN" appears on the
screen, along with fours asterisks ( **** ) that represent the Personal Identification Number
entered using the ×, Ø, Õ, Ö arrow keys. This input has to be confirmed by
pressing the START key.
If the PIN entered is correct, a display like the one reproduced in Display 7
appears on the screen. Use the ×, Ø, Õ, Ö arrow keys to set the voltage and
the time for the welding process according to the fitting manufacturer's
instructions, then press the START key to confirm your input. The "Start ?"
message indicates that the unit is ready to start welding.
(1) The PIN can be obtained from the manufacturer or the reseller and will
be disclosed only to authorized personnel.
6

Configuring the Welding Unit

To reconfigure the welding unit press the Õ and Ö arrow keys simultaneously. This will cause a selection
menu as the one in Displays 8 and 9 to appear on the screen.
Use the ×, Ø arrow keys to select the desired configuration option.
Use the Ö arrow key to toggle between "on" and "off" for that configuration option or access a sub-menu
for options with the symbolic arrow "–>".
Press START to confirm the currently displayed set-up and save it to memory.
6.1

Explanations for the Configuration Menu

"Commission Number on" means that the commission number will have to
be entered or confirmed before every new welding, "off" that it can be
confirmed.
"Welder Code on" means that the welder identification code has to be en-
tered before every welding, "off," that this is impossible.
"Memory Control on" means that when the system memory is full of reports, the unit will be blocked until
the reports are printed off, "off," means that it works but that the oldest
report will be overwritten.
"Set Clock –> " means that by pressing the Ö key, the user can access a
sub-menu for setting the clock.
"Select Language –> " means that by pressing the Ö key, the user can ac-
cess a sub-menu for selecting the display and print language.
6.2

Setting the Clock

When the "Set Clock" sub-menu was selected, the screen changes to the
display reproduced in Display 10.
The time of day and the date can be set using the keypad. The portions
"Hour," "Minute," "Day," "Month," and "Year" are set separately. Press the
START key to confirm your settings.
6.3

Selecting the Display Language

When the "Select Language" sub-menu was selected, the screen changes to
the display reproduced in Display 11, i.e. shows the currently selected
language. Press the arrow key Ö several times to display all available
languages on the screen, one after the other. To select the one that is being
displayed, confirm by pressing the START key.
When another display language was selected, the welding unit
20
Info
(1)
to be
Manual Input
U= 40 V t= 1000 s
Display 7
*** SET-UP MENU ***
>Job No. on
Welder Code off
Memory Control on
Display 8
*** SET-UP MENU ***
Set Clock –>
>Choose Language –>
Display 9
Set Clock/Date
10:25 06.09.07
Display 10
English
Display 11
