5 Operating elements

5 Operating elements
5.1 Trigger 2-cycle function
6 Operation

7 Putting out of operation

EN - 8
NOTE
• As the TIG welding torch is integrated into a welding system, the
operating instructions of the welding components, such as welding torch
and power supply, must be observed during operation.
Using a standard welding torch, the two-cycle mode of the trigger can be
activated.
1 Press the trigger on the handle and keep it pressed = welding is started.
2 Release the trigger = welding is stopped.
WARNING
Electric shock
Equipment parts are energized in the enterprise.
• Do not reach into the danger zone.
1 Open the shielding gas cylinder and start the welding process.
2 After ignition, hold the welding arc near the surface of the material to be
welded until a molten pool is formed.
3 Move the torch uniformly over the entire seam length.
4 Stop the welding process.
5 After switching off, hold the torch over the end position for a few seconds.
This allows the molten pool to solidify without atmospheric interference
under the protection of the gas which is continuing to flow.
1 Switch off power supply.
2 Close the valve of the shielding gas cylinder.
TIG welding torch
