Setup

Signal Connection Diagrams

# C
ONNECTIONS
1 DMX Output/Input
2 Ethernet Input/Throughput

Input Connections Diagram

2
# C
ONNECTIONS
1 DMX In
2 Neutrik® powerCON® In
3 Phoenix Connector
•
•
Net-X II User Manual Rev. 3
1
P
URPOSE
Receive or send DMX input/output to or from controllers or
products. Can receive DMX to be converted to Art-Net™ or sACN.
Link to an Art-Net™ or sACN network; also used to access
webserver
Port A
P
URPOSE
DMX ports A and B.
Power In
To trigger recorded scenes
The Neutrik® etherCON® ports are through ports. Each port can be
either an input or an output port.
The Phoenix Connector has four inputs (triggers 1–4) and a ground
terminal.
2
Port B
1 3
7
