Interconnection
Note:
All wiring must be done in conjunction with approved conduit, boxes, and
fittings and to procedures in accordance with all governing regulations.
Ensure that there is sufficient slack in the cabling to allow the RBSS arm to pivot freely so
the wheel rides on the belt. Restriction of the arm can cause slippage or excessive
contact between the belt and the wheel.
Connection
RBSS CE
RBSS
red
white
black
RBSS IS
RBSS IS
brown
blue
Page EN-6 RBSS Speed Sensor – INSTRUCTION MANUAL
Integrator
excitation
signal
common
IS Switch Isolator
Terminal
1
3
7
8
Integrator
speed signal input
excitation of load cells
