4
Press the SET button to select [INPUT1].
The factory default setting is [OFF]. Each time the
SET button is pressed, the selector function switches
alternately as shown:
3 OFF
INPUT1 2
÷ OFF .......... [AUTO FUNCTION] is disabled.
÷ INPUT1 ..... ÷ When a signal is detected at INPUT1,
the input source automatically
switches to [INPUT1].
÷ After the [AUTO FUNCTION] mode
has caused the input to switch, if the
input signal is no longer detected, the
input source reverts to the one
selected before operation of the
[AUTO FUNCTION] mode.
÷ If the input changes when the unit is
in [AUTO FUNCTION] mode, pressing
the INPUT button to select a different
input will cause the [AUTO
FUNCTION] mode to be temporarily
disabled, but it can be enabled again
by turning the power ON/OFF.
5
When finished with the setting, press the MENU
button to return to the normal screen image.
Notes
÷ The [AUTO FUNCTION] for [INPUT1] is supported only when a
separate SYNC or composite SYNC analog RGB signal is input.
(When a G ON SYNC or component video signal is input,
[AUTO FUNCTION] is disabled.)
÷ The [AUTO FUNCTION] setting affects all input sources.
About audio output (AUDIO OUT)
(PDP-50MXE1/PDP-50MXE1-S/PDP-
43MXE1/PDP-43MXE1-S only)
The signal level produced at the AUDIO (OUTPUT) jack
can be set to [FIXED] or [VARIABLE] (linked to the
VOLUME) as desired.
MENU
5/∞
2/3
SET
Main unit operating
Remote control unit
panel
1
Press the MENU button to display the menu screen.
MENU
CONTRAST
BRIGHTNESS
R.LEVEL
G.LEVEL
B.LEVEL
H.ENHANCE
V.ENHANCE
PICTURE RESET
2
Use the 2/3 buttons to select [OPTION].
MENU
3
Use the 5/∞ buttons to select [AUDIO OUT].
MENU
4
Press the SET button to select the desired audio
level setting.
The factory default setting is [FIXED].
Each time the SET button is pressed, the function
alternates as shown:
÷ FIXED ............ Audio output volume remains fixed,
÷ VARIABLE ..... Audio output volume changes in
5
When finished with the setting, press the MENU
MENU
button to return to the normal screen image.
2/3
Notes
÷ The [AUDIO OUT] setting affects all input sources.
SET
÷ On the PDP-50MXE10/PDP-50MXE11, only [VARIABLE] is
5/∞
supported.
Other Operations
SCREEN
SETUP
OPTION
:
0
:
0
:
0
:
0
:
0
:
0
:
0
SCREEN
SETUP
OPTION
:
LANGUAGE
ENGLISH
:
ENERGY SAVE
STANDARD
:
SCREEN MGT.
OFF
:
ORBITER
OFF
:
MASK CONTROL
ON
:
AUTO SET UP MODE
INACTIVE
:
AUTO FUNCTION
OFF
:
AUDIO OUT
FIXED
ENTER
EXIT
M
N U
S E T
E
SCREEN
SETUP
OPTION
:
LANGUAGE
ENGLISH
:
ENERGY SAVE
STANDARD
SCREEN MGT.
:
OFF
:
ORBITER
OFF
MASK CONTROL
:
ON
:
AUTO SET UP MODE
INACTIVE
:
AUTO FUNCTION
OFF
:
AUDIO OUT
FIXED
CHANGE
M
N U
EXIT
S E T
E
3 FIXED
VARIABLE 2
even if the VOLUME controls are
operated.
response to operation of VOLUME
controls.
INPUT1
INPUT1
INPUT1
33
En
