MACHINE OVERVIEW

1
2
3
4
5
6
7
8
9
10
22 23
1. CUTTING HANDLE
2. BLADE GUARD LOCKING TRIGGER
3. DUST BAG*
4. SLIDE LOCKING SCREW
5. DEPTH GAUGE
6. 2 PC HOLD DOWN CLAMP
7. SLIDING FENCE
8. MACHINE TABLE EXTENSIONS
9. MOUNTING HOLE (X4)
10. FRONT CLAMP HOLES
11. BLADE ROTATION INDICATION ARROW
12. UPPER BLADE GUARD
13. CUTTING HEAD
* Supplied as original equipment on the EU & NA R255SMS+.
†
Supplied as original equipment on the EU R255SMS+ ONLY.
Pictured: R255SMSL (See * for R255SMS+ Parts)
24
EU NA
14. BLADE
15. LOWER BLADE GUARD
16. TABLE TOP
17. ROTARY TABLE
18. TABLE INSERT
19. MITRE HANDLE LOCKING KNOB
20. POSITIVE STOP LOCKING LEVER
21. MITRE ANGLE SCALE
22. SLIDE RAIL PROTECTOR
23. DUSTPORT ADAPTER*
24. 3 PC HOLD DOWN CLAMP*
25. FRONT CLAMP
14
www.evolutionpowertools.com
11
12
13
14
15
16
17
18
19
20
21
25
†
†
