Makita AN935H Manuel D'instruction page 6

► 1. Hook 2. Bolt
Nose adapter
To prevent the surface of workpiece from being
scratched or damaged, use the nose adapter.
To detach the nose adapter from its housing base, pull
the nose adapter in the direction of the arrow.
1
► 1. Nose adapter
To attach the nose adapter to the contact element,
press it onto the contact element until the recessed
parts in four places inside the nose adapter fit in four
protrusions of the contact element.
3
1
► 1. Nose adapter 2. Contact element 3. Protrusion
4. Recessed part
2
1
2
4
Air duster
CAUTION:
Do not aim the ejection port of the
air duster to someone. Also, keep your hands and
foot away from the ejection port. If the air duster
button is accidentally pushed, it may cause a per-
sonal injury.
CAUTION:
Always check your surroundings
before using the air duster. Blown dust or objects
may hit someone.
CAUTION:
Do not connect or disconnect the
air hose while pushing the air duster button.
The air supplied to the tool can also be used as an air
duster. You can clean the work area by pressing the
button on the grip end.
► 1. Button
NOTICE:
After using the air duster, the driving force
of the tool will temporarily decline. Wait until the air
pressure recovers in this case.
NOTICE:
Perform a test blow if you use the air
duster immediately after the oil was applied. The oil
may be sprayed with the air.
ASSEMBLY
CAUTION:
Before carrying out any work on
the tool, always lock the trigger by turning the
trigger lock lever to the lock position
disconnect the air hose from the tool.
Loading nailer
CAUTION:
Do not use deformed nails or
linked sheet.
1. Disconnect the air hose.
2. Depress the latch lever and open the door and
magazine cap.
6 ENGLISH
1
, and
