Transmission gear display
Numbers on the meter indicate the gear
positions of the vehicle including 1, 2, 3,
4 and5.
Anti-lock Brake System (ABS) warning
light
1. ABS error: whenever any fault is de-
tected and saved, the ABS diagnostic light
is on.
The ABS diagnostic light will turn off with
the next SHUTDOWN/ IGNITION of the in-
strument panel or when the vehicle exce-
eds the speed of about 5 km/h.
2. Disabled ABS mode: the ABS diagno-
stic light will flash once for about 1.30 se-
conds (short flashing).
3. By keeping the ABS button pressed for a
time of 3/30 seconds, the ABS diagnostic
light will flash once for about 0.30 se-
conds (short flashing).
4. ABS activated: When the instrument
panel is on, the ABS diagnostic light will
be on until the vehicle reaches the speed
of about 5 km/h. Once having exceeded
this speed, the diagnostic light will turn
off.
WARNING
Usually the ABS diagnostic light stays
on when the instrument panel is swi-
tched on and turns off when the vehicle
speed is above 5 km/h.
Is the ABS diagnostic light shows one of
the following symptoms, one or more fau-
lts may have been occurred on the ABS
system.
• The ABS diagnostic light does not
go on when the instrument panel is
switched on.
• The ABS diagnostic light will stay on
even when the vehicle exceeds the
speed of about 5 km/h.
In which event, take the motorcycle to an
authorized Benelli service centre.
It is important to point out the fact that
the ABS is not active when the light is
on, but the braking system will continue
working as a normal system not equipped
with ABS.
In this situation, a hard braking may lock
the wheels, causing slip and loss of stabili-
ty of the motorcycle.
3 - 5
Instrument and control functions
Reserve fuel indicator
Comes on when approximately 2 litres of
fuel are left; in this case, fill up the tank as
soon as possible.
