Adjusting the volume
Your Midland BTNEXT PRO uses AGC technology, which automatically adjusts the
listening volume in relation to background noises.
However, it is also possible to manually adjust the volume by means of the "Volume +"
and "Volume -"buttons. The volume setting is indipendent for each audio source:
intercom, stereo music, phone call, FM radio.
Attention: volume can be adjusted only when an audio connection is active.

Set up of the AGC system

To adjust the sensitivity of the AGC system you can use the "BT UPDATER" Pc Softwa-
re or the smartphone "BT SET-APP" application. You can choose different set up based
on your motorbike type (naked, touring, sport) or if you are riding as a passenger. You
can disable the AGC system pressing "Volume +" and "Volume -" togheter for 3 sec.
How to pair the Midland BTNEXT PRO to more than two units
One Midland BTNEXT PRO unit can be paired to maximum five other BT units, that
means six in total (3 Midland unit + 2 Talk2All + yourself).
The Midland BTNEXT PRO has three main buttons (Forward, Middle and Rear). It is
up to you which button to use to pair and activate the intercom, you are totally free to
choose the button you like more. The same button you will use to pair the unit will be
also used to activate the intercom communication. Remember that each device can
always be paired with other 3 units at your choice; as shown in the picture here below,
also 'crossed' pairing can be done.
Passenger 1
Rider 2
www.midlandeurope.com
Rider 1
Rider 3
For example you can decide to pair one motorbike rider unit to the Forward button, your
passenger to the Middle button and another rider to the Rear button.
In this way you can have in total 4 units paired together and talk to each person, one by
one, simply by pressing the corresponding button (the same used for the pairing). Every
time you open the intercom connection to one person, the previous connection will be
closed. The connection is not a "chain", when two persons are talking it is not possible to
break (interrupt) the communication by one of the other two units.
Pair the Midland BTNEXT PRO to another Midland BTNEXT PRO unit
To pair the Midland BTNEXT PRO to another Midland BTNEXT PRO unit, you must
first enter the setup mode:
1. Turn off the unit
2. Press and hold down the middle button about 7 sec., until the Red light is on per-
manently.
3. Now press one of the three buttons (Forward, Middle or Backward) for 3 seconds
depending on which button you would like use to open the intercom to the other
unit. The Blue and Red lights will flash.
4. Repeat the same procedure on the other unit, you don't need to use the same but-
ton, you can choose one of the three buttons not previously used.
5. When successfully paired, each unit will have the Blue light on for one second and
then go back to the setup mode (Red light always on).
6. Now the unit is ready for another pairing procedure, and you can pair another Mi-
dland BTNEXT PRO unit following the same procedure, but using a different button.
If you don't have more devices to pair, you must exit the setup mode before you can
use the units:
› Double click on the Middle button, the Red light will turn off and the Blue light will
start flashing. You can use now your Midland BTNEXT PRO
How to use the Intercom with more than two units
To use the intercom feature, be sure that all the units are turned on and correctly paired
together.
Manual activation in Intercom mode
When in "Intercom Mode" press the button corresponding to the unit you would like
to communicate with. After some seconds the intercom communication will open. The
