English
Definitions
1. Manual Fuel Pump
Provides additional fuel feed for a
cold start.
2. Fuel Filler Cap
For closing the fuel tank.
3. Fuel Tank
For fuel and oil mixture.
4. Starter Grip
The grip of the pull starter, for
starting the engine.
5. Muffler with Spark Arresting Screen
Muffler reduces exhaust noises and
diverts exhaust gases away from
operator. Spark arresting screen is
designed to reduce the risk of fire.
6. Carburetor Adjusting Screws
For tuning the carburetor.
7. Choke Lever
Eases engine starting by enriching
mixture.
8. Air Filter Cover
Covers and protects the air filter
element.
9. Spark Plug Boot
Connects the spark plug with the
ignition lead.
10. Machine Support
For resting machine on the ground.
11. Throttle Trigger
Controls the speed of the engine.
12. Throttle Trigger Lockout
Must be depressed before the
throttle trigger can be activated.
20
13. Stop Switch
Switches the engine's ignition off
and stops the engine.
14. Carrying Ring
Connects the trimmer/brushcutter to
the harness.
15. Loop Handle
For easy control of machine during
cutting work.
16. Barrier Bar
Helps keep user's feet and legs
clear of the cutting attachment.
17. Drive Tube
Encloses and protects the drive
shaft between the engine and
coupling sleeve.
18. Coupling Sleeve
Connects drive tube to lower part of
drive tube (stub shaft).
19. Wing Screw
Secures lower part of the drive tube
(stub shaft).
20. Sleeve
Maintains minimum clearance
between control handle and loop
handle.

Specifications

EPA / CEPA
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category
A = 300 hours
B = 125 hours
C = 50 hours
Engine
Single cylinder two-stroke engine
Displacement: 27.2 cc
Bore: 34 mm
Stroke: 30 mm
Engine power to 0.8 kW (1.1 bhp)
ISO 8893: at 8,500 rpm
Idle speed: 2,800 rpm
Cut-off speed (rated): 10,000 rpm
Ignition System
Electronic magneto ignition
Spark plug (resistor
type): NGK CMR 6 H
Electrode gap: 0.5 mm
KM 56 R, KM 56 RC
