ENGLISH
3.3
SAFETY INFO LABELS: LOCATION
11
HOURMETER
ON
MCH 16/ETS SUPER SILENT EVO
3.3.1
Safety info labels: description
1
Do not use the compressor without having first read the instruction manual
supplied with the machine and observed the instructions. The user shall
pay all necessary attention and adopt appropriate control devices, safety
and protection for vessels which have indicated, on the test certificate,
maximum working pressure lower than that indicated on compressor.
18 - 56
10
PRESSOSTATO
MANOMETRO
MANOMETRO
PRESSURE
3° STADIO
SWITCH
PRESSURE GAUGE
PRESSURE GAUGE
3° STAGE
230 Volt
HOURMETER
1
OFF
TEST
LOW
WRONG
PURGE
LEVEL OIL
ROTATION
7
12
2
SCARICO CONDENSA
CONDENSATE DISCHARGE
4
ATTENZIONE
CONTROLLARE IL LIVELLO DELL'OLIO
OGNI 50 ORE E SOSTITUIRLO OGNI
250 ORE DI LAVORO
WARNING
CHECK OIL LEVEL EVERY 50 HOURS
AND CHANGE OIL EVERY
250 WORKING HOURS
5
SCARICO OLIO
OIL DRAIN
9
MCH-13-16-18 SILENT
FRANÇAIS
3.3
EMPLACEMENT DES PLAQUES DE SÉCURITÉ
MANOMETRO
2° STADIO
1° STADIO
PRESSURE GAUGE
2° STAGE
1° STAGE
AEROTECNICA COLTRI S.r.l.
Via Colli Storici 177
25010 DESENZANO D/G (BS) ITALY
Tel. 030/9910301-9910297
Fax. 030/9910283
MODEL
MCH 16/ETS SUPER SILENT EVO
TYPE
SUPER SILENT EVO
S/N.
0000
YEAR
2008
MOTOR
THREE-PHASE
POWER
2 x 6,6 Kw
FILTRO CON CARTUCCIA DA
SOSTITUIRE AD INTERVALLI
REGOLARI - VEDI MANUALE
FILTER WITH CARTRIDGE
TO BE REPLACED AT REGULAR
INTERVALS – SEE MANUAL
8
3.3.1
Description des plaques de sécurité
Ne pas utiliser le compresseur sans avoir lu le manuel d'utilisation fourni
avec la machine et se conformer aux instructions. Il faut que l'utilisateur
prête attention et se munisse des dispositif de réglage e de protection,
aptes à remplir les réservoirs, qui ont indiqué sur le attestation d'essais
une pression de service maximale moins grande que celle iniquée sur le
compresseur.
6
3
MU-MCH1316S-0717
