6. Set up

BLOWER TUBES
1. Connect the blower and swivel joint with flexible
hose. Clamp both ends of the flexible hose securely
with the hardware supplied with the unit.
2. Align the protrusion and the groove provided on
the tube ends and twist the tube until connection is
locked up.
NOTE
A light lubricant may be used to ease assembly of flex-
ible pipe to blower elbow.
THROTTLE LEVER
• Set up the clamp to the swivel and tighten the screw
on the clamp.
THROTTLE CABLE
• Use the clamp to fasten the colgate tube containing
the throttle cable and the power cable to the hose.
GB-8
WAIST BELT
• The waist belt is attached to the rings on the left and
• Be sure to always tighten the buckle in front of your
• If you are not using a waist belt, be sure to remove it
• There is a risk that the belt will be caught, toppling
• There is a danger that the belt will be sucked into
(1) Clamp
(2) Swivel
(3) Screw
(1) Clamp
(2) Cable
(3) Hose
right sides of the frame.
body.
WARNING
from the unit and store it.
the unit.
the fan.
